Amphenol Industrial SURLOK PLUS RADSOK EV Connector Female 200A Panel Mount, 1000V, IP67 SLPRB50CPSR / C10-730189-200
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Red |
| Orientation | Straight |
| Current | 200A |
| Height | 30mm |
| Model | SLPRB50CPSR / C10-730189-200 |
| Depth | 53.7mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 30mm |
| Mount Type | Panel Mount |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 8mm |
| Number of Rows | 1 |
| Wire size | 50mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Plug |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Connector Gender | Female |
| Better World Claim | Renewable Energy Solution |
Key Features
- The connector supports a current rating of 200 amperes.
- It operates at an operating voltage of 1000 volts with IP67 environmental sealing.
- The RADSOK technology provides a high tensile strength and highly conductive surface.
- Constructed with copper alloy contacts and thermoplastic housing for durability and flame resistance (UL 94-V0).
- Features include touch proof design, spring locking, and keyed mating to prevent mismating.
- Suitable for electric vehicle, rail mass transit, process control, medical, and battery management system applications.
- Operating temperature range from -40°C to 125°C ensures performance in harsh environments.
- Compact design with 8mm pin diameter and wire size compatibility of 50mm².
Product Description
Amphenol Industrial SLPRB50CPSR / C10-730189-200 SURLOK PLUS RADSOK EV Connector Female is a panel mount connector designed for high-current electric vehicle and industrial applications. It supports a current rating of 200A and operates at 1000V, offering a reliable and robust electrical connection with environmental protection rated at IP67.
This connector utilizes RADSOK technology for superior contact performance, ensuring high tensile strength and a highly conductive contact surface. The connector has a single row and single contact, specifically designed for 50mm² wire sizes with an 8mm pin diameter.
The construction features copper alloy contacts and a thermoplastic housing, complying with UL 94-V0 flammability standards. It incorporates spring locking and a keyed design to prevent mismating and guarantee secure connections. The connector operates reliably within a temperature range of -40°C to 125°C.
This connector is extensively used in electric vehicle (EV/HEV) applications, rail mass transit systems, process control environments, medical equipment, and battery management systems (BMS) or energy storage solutions.
Dimensions include a height and width of 30mm and a depth of 53.7mm, with a straight orientation for convenient panel mounting. The connector is red in color and is classified as a Better World product supporting renewable energy solutions.
The connector’s design is touch proof enhancing user safety. Environmental sealing to IP67 ensures reliable operation in harsh conditions. Panel mount flange allows easy and secure installation. RADSOK spring locking mechanism provides high retention and conductivity.
Keyed design prevents incorrect connections ensuring system reliability.
This EV connector by Amphenol Industrial combines robust material construction with advanced contact technology, providing an ideal solution for demanding automotive and industrial power connections.
Explore the full range of Amphenol Industrial EV Connectors and related components at EnvMart for reliable industrial-grade electrical connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 200 amperes.
The maximum operating voltage is 1000 volts.
This connector has an IP67 environmental sealing rating, ensuring protection against dust and water ingress.
It features copper alloy contacts and a thermoplastic housing, complying with UL 94-V0 flammability standards.
The operating temperature range is from -40°C to 125°C.
The pin diameter is 8mm, and it is compatible with wire sizes of 50mm².
It incorporates a keyed design to prevent mismating and ensure secure connections.
This model is designed for panel mount installation.
It is suitable for electric vehicles, rail mass transit, process control, medical applications, and battery management systems.
It features a touch-proof design to enhance user safety.
The connector has a straight orientation for convenient panel mounting.
This connector has a single contact and is classified as a female connector.
