RS PRO Right Angle Through Hole PCB Header, 10 Contacts, 2.54 mm Pitch, Shrouded, Gold Plated, Thermoplastic Housing 471-109
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | RS PRO |
| Orientation | Right Angle |
| Current | 1A |
| Model | 471-109 |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -45°C |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Hirose 10-Way IDC Connector Plug Through Hole Mount, 2-RowBrand | Hirose |
Key Features
- The connector features a thermoplastic housing rated UL94V for durability and safety.
- Gold flash plated contacts ensure low resistance and corrosion protection.
- Designed for through hole mounting, facilitating secure soldering to PCBs.
- Male contact gender with solder termination type for easy assembly.
- Operating temperature range from -45°C to 105°C ensures performance in diverse environments.
- Shrouded design includes long ejection latches for secure mating and protection.
- Compatible with IDC ribbon cable sockets conforming to BS9525-F0023 standard.
- Application versatility includes industrial automation, medical equipment, consumer electronics, and prototype development.
Product Description
RS PRO 471-109 is a right angle, through hole PCB header featuring 10 male contacts arranged with 2.54 mm pitch spacing, encapsulated in a shrouded thermoplastic housing. This component is designed for robust electrical connections on printed circuit boards where space efficiency and reliable contact protection are required.
The UL94V rated glass-filled polyester housing offers excellent insulation properties and mechanical strength. The gold flash plated contacts provide superior conductivity and resistance to oxidation over time, essential for industrial and commercial electronics applications.
The connector supports a current rating of 1A, suitable for low power signal connections. Its temperature operating range spans from -45°C to 105°C, allowing usage in demanding environments such as industrial automation and medical instrumentation.
Mounting is via through hole solder termination, ensuring durable mechanical and electrical stability. The shrouded and right-angle orientation design improves connector protection and eases cable routing on crowded PCB assemblies.
This RS PRO connector is compatible with universal IDC ribbon cable sockets and box headers adhering to the BS9525-F0023 standard, supporting rapid cable insertion with strain relief for secure termination.
The thermoplastic housing ensures safety and durability under electrical load. Gold plated contacts prevent corrosion-related failures. Through hole mount type facilitates secure soldering onto PCBs. Shrouded design with ejection latches supports reliable connections.
Rated current of 1 ampere for signal integrity in electronic circuits. Operating temperature range allows usage in extreme environmental conditions. Manufactured in Taiwan, indicating high manufacturing standards. Widely applicable for prototype development, industrial automation, consumer electronics, and medical equipment.
This PCB Header is an integral component for engineers requiring dependable board connections with compact right angle design, providing enhanced usability in high-density circuit applications. Explore more RS PRO connectors and electronic components at EnvMart for comprehensive electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The PCB header has a current rating of 1A, suitable for low power signal connections.
The contacts are arranged with a pitch of 2.54 mm, which is standard for many PCB applications.
It operates within a temperature range of -45°C to 105°C, making it suitable for diverse environmental conditions.
This model uses through hole mounting, facilitating secure soldering to printed circuit boards.
The housing is made of thermoplastic, which is rated UL94V for durability and safety.
This PCB header features 10 male contacts, arranged for efficient connections.
Yes, it is compatible with IDC ribbon cable sockets that conform to the BS9525-F0023 standard.
The connector features a right angle design, which helps with cable routing in crowded PCB assemblies.
The contacts are gold flash plated, providing low resistance and corrosion protection.
This model is manufactured in Taiwan, indicating adherence to high manufacturing standards.
It is versatile for applications in industrial automation, medical equipment, consumer electronics, and prototype development.
This connector uses a solder termination type for easy assembly and reliable connections.
