ABB High Performance S800N Miniature Circuit Breaker, 2-Pole, 63A, Type C, 690V AC, 250V DC, 36 kA 2CCS892001R0634 S802N-C63

ABB 2CCS892001R0634 S802N-C63 is a high performance S800N series miniature circuit breaker designed for robust electrical circuit protection in industrial, commercial, and renewable energy systems. It features a 2-pole design supporting a rated current of 63A, making it well-suited for heavy-duty applications.

This circuit breaker employs Type C tripping characteristics, suitable for protection against moderate inductive loads and short circuits. It operates effectively at rated voltages of 690V AC and 250V DC, thus providing versatile application across AC and DC installations.

The device mounts easily on a standard DIN rail with screw terminals, ensuring flexible and secure wiring connections. Its thermomagnetic and electromagnetic dual tripping mechanism ensures precise and reliable protection under overload and short-circuit conditions. The toggle switch actuator allows quick manual resets to minimize downtime.

With a breaking capacity of 36 kA, the breaker guarantees high circuit safety and durability, essential for industrial power distribution, commercial electrical installations, automation control circuits, and renewable energy systems. Its compact dimensions (95mm height, 54mm width, 82.5mm depth) and IP20 enclosure rating suit standard electrical panels, offering space efficiency and protection against contact.

Manufactured in Switzerland, this ABB S800N miniature circuit breaker complies with IEC/EN 60947-2 and IEC/EN 60898-1 standards, ensuring international quality and safety benchmarks.

Type C tripping provides protection against overloads. 2-pole configuration for effective circuit management. Rated current of 63A for demanding electrical loads. DIN rail mounting for straightforward installation. Rated voltage of 690V AC and 250V DC for versatile use.

36 kA breaking capacity enhances circuit safety. Thermomagnetic and electromagnetic tripping mechanisms. Toggle switch actuator for easy manual reset. Screw terminal connections ensure reliable wiring. IP20 protection rating supports safe operation.

This miniature circuit breaker is ideal for protecting industrial power distribution networks, commercial electrical installations, automation and control circuits, renewable energy systems, and public buildings requiring enhanced safety. ABB's commitment to quality and safety standards makes this an excellent choice for a variety of demanding electrical applications.
