ABB High Performance S800N Miniature Circuit Breaker, 3-Pole, 100A, Type C, 690V AC, 375V DC, 36kA Breaking 2CCG001233R0001
Specifications
| Country of Origin | Switzerland |
|---|---|
| Range | High Performance |
| Brand | ABB |
| Height | 95mm |
| Model | 2CCG001233R0001 |
| Depth | 88.5mm |
| IP Rating | IP20 |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 100A |
| Series | S800N |
| Terminal type | Screw |
| Breaking Capacity | 36kA |
| Number of Poles | 3 |
| Standards/Approvals | IEC/EN 60898-1, IEC/EN 60947-2 |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 375V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Electromagnetic, Thermomagnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Designed for DIN Rail mounting to ensure easy installation.
- Rated current of 100A suitable for medium power circuits.
- Supports AC voltages up to 690V and DC voltages up to 375V.
- Breaking capacity of 36 kA allows effective fault isolation.
- C type tripping characteristics enable fast response to overloads.
- Durable toggle switch actuator allows easy manual reset.
- Compact dimensions optimize use of panel space.
- Compliance with IEC and EN standards assures safety and reliability.
Product Description
ABB 2CCG001233R0001 High Performance S800N Miniature Circuit Breaker is a 3-pole device rated at 100 amperes, designed for use in both AC and DC electrical distribution systems. It operates safely under rated AC voltages of 690 volts and DC voltages up to 375 volts, providing reliable protection against overloads and short circuits.
Its thermomagnetic tripping mechanism ensures rapid isolation during fault conditions, protecting connected equipment effectively. The type C tripping characteristic offers quicker response times suitable for applications where moderate inrush currents are expected, such as motors and transformers.
The device features a robust toggle switch actuator for manual resetting, mounted on a DIN Rail compatible design to facilitate quick installation and maintenance within electrical panels. Measuring 95 mm in height, 80 mm in width, and 88.5 mm in depth, the breaker fits compactly in distribution boards, optimizing panel space usage.
Conforming to IEC/EN 60898-1 and IEC/EN 60947-2 standards, this MCB guarantees operational safety and performance. It includes an IP20 ingress protection rating, protecting against accidental contact and solid foreign objects.
This Miniature Circuit Breaker is widely used in industrial automation, electrical distribution panels, residential installations, and commercial motor protection applications. DIN Rail mounting for ease of installation.
100A current rating suitable for medium power circuits. 690V AC and 375V DC operational voltage ratings. 36 kA breaking capacity for effective fault isolation. Type C tripping characteristics for fast overload response. Toggle switch actuator allows easy manual reset.
Compact size optimizes panel space utilization. Adheres to IEC and EN safety standards. Thermomagnetic trip mechanism combines electromagnetic and thermal protections. IP20 rating for protection against solid objects. Manufactured in Switzerland for quality assurance.
Explore more ABB circuit breakers and electrical protection devices at EnvMart for reliable industrial and commercial electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a current rating of 100A, suitable for medium power circuits.
This model supports rated AC voltages up to 690V and DC voltages up to 375V.
It features a breaking capacity of 36 kA, allowing effective fault isolation.
It has Type C tripping characteristics, which enable a fast response to overloads, suitable for applications with moderate inrush currents.
This unit is designed for DIN Rail mounting, which facilitates easy installation and maintenance.
It measures 95 mm in height, 80 mm in width, and 88.5 mm in depth.
It has an IP20 ingress protection rating, which protects against accidental contact and solid foreign objects.
It conforms to IEC/EN 60898-1 and IEC/EN 60947-2 standards, ensuring operational safety and performance.
It features a toggle switch actuator that allows for easy manual resetting.
This product is manufactured in Switzerland.
It employs a thermomagnetic tripping mechanism that combines electromagnetic and thermal protections.
It is widely used in industrial automation, electrical distribution panels, residential installations, and commercial motor protection applications.
