ABB High Performance S800S Miniature Circuit Breaker, 3-Pole, 63A, Type B, 690V AC, 250V DC, 50 kA 2CCS863001R0635 S803S-B63
Specifications
| Country of Origin | Switzerland |
|---|---|
| Range | High Performance |
| Brand | ABB |
| Height | 95mm |
| Model | 2CCS863001R0635 S803S-B63 |
| Depth | 88.5mm |
| IP Rating | IP20 |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 63A |
| Series | S800S |
| Terminal type | Screw |
| Breaking Capacity | 50kA |
| Number of Poles | 3 |
| Standards/Approvals | IEC/EN 60898-1, IEC/EN 60947-2 |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 250V |
| Tripping Characteristics | Type B |
| Tripping Mechanism | Electromagnetic, Thermomagnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Designed for DIN rail mounting with compact dimensions.
- Capable of withstanding short circuits up to 50 kA breaking capacity.
- Supports operation at up to 690V AC and 250V DC voltages.
- Equipped with screw terminals for secure connections.
- Reset is simple with an easy-to-use toggle switch.
- Contains a thermal and electromagnetic tripping mechanism for reliable overload protection.
- IP20 rated to protect against solid objects and limited ingress.
- Suitable for commercial, industrial, and residential electrical panels.
Product Description
ABB 2CCS863001R0635 S803S-B63 is a high-performance miniature circuit breaker designed for robust electrical protection in industrial, commercial, and residential applications. Featuring a 3-pole configuration and a current rating of 63A, this device supports both alternating current (up to 690V AC) and direct current (up to 250V DC).
Its compact size with dimensions of 80mm (width) by 95mm (height) and 88.5mm (depth) makes it ideal for DIN rail mounting in electrical distribution panels. The breaker utilizes a combined electromagnetic and thermomagnetic tripping mechanism that ensures precise disconnection during both overload and short circuit conditions, enhancing system safety.
The device is equipped with screw-type terminals to provide secure and reliable wiring connections. User-friendly toggle switch actuator allows for quick and straightforward manual resetting after tripping events. With an IP20 rating, it provides protection against intrusion of solid objects larger than 12 mm.
Designed according to IEC/EN 60898-1 and IEC/EN 60947-2 standards, the breaker guarantees conformity and reliability in industrial automation, electrical installations, and building protection systems. The 50 kA breaking capacity offers high resilience to short circuit faults, making it a reliable safeguard in demanding environments.
Applications include commercial electrical panels, integration within industrial automation systems, and residential installations requiring dependable overload and short circuit protection. Its high-performance characteristics make it suitable for usage in both AC and DC electrical systems.
Designed for DIN rail mounting with compact size. Thermal and electromagnetic tripping for overload and short circuit protection. High breaking capacity of 50 kA supports fault current interruptions. Operates safely at rated voltages up to 690V AC and 250V DC.
Screw terminals provide secure wiring connections. Toggle switch actuator enables easy manual reset. IP20 protection rating suitable for indoor industrial environments. Compliant with IEC/EN 60898-1 and IEC/EN 60947-2 safety standards.
Applicable in commercial, industrial, and residential electrical setups. Explore more about ABB products and Miniature Circuit Breakers in our Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ABB High Performance S800S Miniature Circuit Breaker has a breaking capacity of 50 kA, allowing it to withstand short circuit conditions effectively.
It operates safely at rated voltages of up to 690V AC and 250V DC, making it suitable for various electrical systems.
This model is designed for DIN rail mounting, which facilitates easy installation in electrical distribution panels.
The current rating for this miniature circuit breaker is 63A, which determines the maximum load it can handle.
The dimensions of the circuit breaker are 80mm in width, 95mm in height, and 88.5mm in depth.
It utilizes a combined electromagnetic and thermomagnetic tripping mechanism for reliable overload and short circuit protection.
The breaker has an IP20 rating, which provides protection against solid objects larger than 12 mm.
It is designed in accordance with IEC/EN 60898-1 and IEC/EN 60947-2 standards, ensuring reliability and safety in electrical installations.
This circuit breaker is equipped with screw-type terminals, providing secure and reliable wiring connections.
It is suitable for use in commercial, industrial, and residential electrical panels, providing dependable overload and short circuit protection.
Resetting this model is simple, using an easy-to-use toggle switch actuator for manual resetting after tripping events.
This product is part of the S800S series, known for its high performance in electrical protection.
