ABB High Performance S800N Miniature Circuit Breaker, 2-Pole, 100A, Type D, 690V AC, 250V DC, 36 kA Breaking 2CCG001242R0001
Specifications
| Country of Origin | Switzerland |
|---|---|
| Range | High Performance |
| Brand | ABB |
| Height | 95mm |
| Model | 2CCG001242R0001 |
| Depth | 82.5mm |
| IP Rating | IP20 |
| Width | 54mm |
| Mount Type | DIN Rail |
| Current Rating | 100A |
| Series | S800N |
| Terminal type | Screw |
| Breaking Capacity | 36kA |
| Number of Poles | 2 |
| Standards/Approvals | IEC/EN 60898-1, IEC/EN 60947-2 |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 250V dc |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermomagnetic, Electromagnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Designed for robust circuit protection in industrial and commercial electrical systems.
- Equipped with a thermomagnetic and electromagnetic tripping mechanism for reliable operation.
- Features a compact DIN rail mountable design with a toggle switch reset actuator.
- Rated to withstand breaking capacities up to 36 kA for high fault current scenarios.
- Operates at 690V AC and 250V DC for versatile electrical applications.
- Constructed to IEC/EN 60898-1 and IEC/EN 60947-2 standards ensuring international compliance.
- Provides IP20 protection rating suitable for indoor electrical enclosures.
Product Description
ABB 2CCG001242R0001 Miniature Circuit Breaker is a high-performance electrical protection device designed for industrial and commercial applications requiring precise and reliable circuit interruption. This 2-pole MCB features a current rating of 100A and Type D tripping characteristics that provide enhanced protection against short circuits and overloads.
Engineered with thermomagnetic and electromagnetic tripping mechanisms, this circuit breaker responds efficiently to both thermal and instantaneous fault conditions, ensuring system safety. It accepts an AC voltage of up to 690V and DC voltage up to 250V, accommodating diverse electrical configurations.
The compact design measures 54 mm in width, 95 mm in height, and 82.5 mm in depth, allowing seamless installation on standard DIN rails within electrical panels. The toggle switch actuator enables easy manual reset and operation after a fault event.
With a breaking capacity of 36 kA, the device can safely interrupt high fault currents, safeguarding your electrical circuits from damage. The IP20 rating offers protection against solid objects larger than 12.5 mm while indicating indoor application suitability.
Constructed in compliance with IEC/EN 60898-1 and IEC/EN 60947-2 standards, this MCB meets rigorous safety and performance criteria required in many industrial and manufacturing environments.
Robust 2-pole circuit protection with 100A current rating. Thermomagnetic and electromagnetic tripping for effective fault detection. High breaking capacity of 36 kA for fault current safety. Dependency on DIN rail mounting for compact electrical panels.
Toggle switch actuator for manual reset convenience. Voltage ratings of 690V AC and 250V DC cover varied power systems. Protection rating IP20 for indoor electrical enclosure use. Compliance with international IEC/EN electrical standards.
This Miniature Circuit Breaker is ideal for use in industrial control panels, automation electrical systems, manufacturing facilities, and commercial power distribution boards. It ensures reliable interruption of electrical faults and protects critical electrical assets.
Explore more high-performance circuit protection solutions in the ABB product range available at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 100A, making it suitable for robust circuit protection in various applications.
It operates at a rated AC voltage of 690V and a rated DC voltage of 250V, accommodating diverse electrical configurations.
The breaking capacity of this unit is 36 kA, allowing it to safely interrupt high fault currents.
It features both thermomagnetic and electromagnetic tripping mechanisms for effective fault detection.
This model is designed for DIN rail mounting, facilitating easy installation in standard electrical panels.
It has an IP20 protection rating, suitable for indoor electrical enclosures and protection against solid objects larger than 12.5 mm.
The dimensions of this unit are 54 mm in width, 95 mm in height, and 82.5 mm in depth.
This model has Type D tripping characteristics, which provide enhanced protection against short circuits and overloads.
It is constructed to comply with IEC/EN 60898-1 and IEC/EN 60947-2 standards, ensuring international safety and performance criteria.
It is equipped with a toggle switch reset actuator, allowing for easy manual reset after a fault event.
The country of origin for this model is Switzerland, reflecting its high-performance engineering standards.
It is ideal for use in industrial control panels, automation electrical systems, manufacturing facilities, and commercial power distribution boards.
