Microchip 8-bit PIC Microcontroller PIC16F1503-E/ST, 20 MHz, 3.5kB FLASH, 14-Pin TSSOP PIC16F1503-E/ST

Microchip PIC16F1503-E/ST is an 8-bit PIC microcontroller designed for embedded applications requiring reliable performance and compact size. Featuring a 20 MHz maximum clock frequency and 3.5 KB of FLASH program memory paired with 128 bytes of RAM, this microcontroller supports efficient data processing.

The device includes a versatile set of peripherals, such as 22 programmable input/output pins, three timers, an 8-channel 10-bit analog-to-digital converter (ADC), digital-to-analog converter (DAC), and two analog comparators. It operates on a supply voltage ranging from 1.8 V to 5.5 V with a maximum power dissipation of 800 mW, making it suitable for low power embedded designs.

The PIC16F1503 uses a reduced instruction set computer (RISC) architecture with 49 instructions and a 16-level hardware stack, providing up to 5 million instructions per second (MIPS) for efficient task execution. It supports in-circuit serial programming (ICSP) and in-circuit debugging (ICD), which facilitate development and testing.

Robust features include power-on reset (POR), power-up timer (PWRT), programmable low power brown-out reset (LPBOR), and an extended watchdog timer (WDT) to improve system reliability. The microcontroller package is a 14-pin TSSOP, with compact dimensions 5.1 x 4.5 x 1.05 mm, allowing for space-efficient PCB layouts.

Operating temperature is rated from -40°C to +125°C, enabling use in industrial and commercial environments. The device complies with RoHS standards, ensuring environmental safety.

Features an 8-bit PIC core operating at up to 20 MHz for fast processing. Includes 3.5kB FLASH program memory and 128 bytes of RAM data memory. Offers versatile peripherals including ADC, DAC, comparators, and timers. Supports a wide operating voltage range of 1.8 V to 5.5 V for flexible power supply use.

Compact 14-Pin TSSOP package dimensions: 5.1 mm length, 4.5 mm width, 1.05 mm height.

This microcontroller is ideal for industrial control, consumer electronics, and embedded system designs requiring a compact, low power, and feature-rich 8-bit solution. Explore a wide range of Microchip PIC Microcontrollers for your application on EnvMart.
