Amphenol Limited MIL Spec Circular Connector Copper Alloy Straight 6 Contacts Wall Mount 400-500V AC 5A TVP00ZN-09-35SN
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 400, 500V ac |
| Brand | Amphenol Limited |
| Colour | Black |
| Orientation | Straight |
| Current | 5A |
| Model | TVP00ZN-09-35SN |
| Mount Type | Wall Mount |
| Housing Material | Aluminium |
| Contact Material | Copper Alloy |
| Series | TV |
| Termination Type | Solder |
| Maximum Operating Temperature | 175°C |
| Minimum Operating Temperature | -65°C |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shell Size | 09 |
| Military Standard | MIL-DTL-38999 |
| Mating Type | Screw Coupling |
| Connector Size | Standard |
| Shell Plating | Black Zinc Nickel |
Key Features
- Complies with MIL-DTL-38999 Series III Class Z standards for rugged performance.
- Operates under a voltage range of 400 to 500 volts AC and current rating of 5 amperes.
- Features black zinc nickel plated aluminium housing with black colour and straight orientation.
- Supports temperature range from -65°C to 175°C, suitable for extreme environments.
- Wall mount connector with screw coupling and solder termination type for secure connections.
- Provides salt spray resistance of 500 hours and up to 500 mating cycles for longevity.
- Contact material is copper alloy with gold plating to ensure reliable conductivity and corrosion resistance.
- Includes strain relief mechanism to protect cable integrity and connector reliability.
Product Description
Amphenol Limited TVP00ZN-09-35SN is a high-performance MIL Spec Circular Connector designed for demanding military, industrial, and aerospace applications requiring reliable and robust connectivity. This connector is part of the MIL-DTL-38999 Series III Class Z featuring black zinc nickel plating on an aluminium housing to enhance corrosion resistance and durability, while complying with RoHS requirements for environmental safety.
The connector incorporates 6 female copper alloy contacts plated with gold to ensure optimal electrical conductivity and longevity. It supports an operating voltage range of 400 to 500 volts AC and is rated for a continuous current of 5 amperes, making it suitable for various electrical systems. The temperature tolerance ranges from -65°C to a maximum of 175°C, allowing for reliable operation in extreme conditions including military vehicles, aircraft, submarines, and critical communication equipment.
Designed as a straight orientation wall mount with screw coupling and solder termination, the connector ensures secure and stable electrical connections. With proven resistance to salt spray for 500 hours and capability of withstanding up to 500 mating cycles, this connector is engineered for longevity and durability in harsh environments. The strain relief feature further safeguards the cable and connector interface against mechanical stress.
These attributes make the Amphenol Limited TVP00ZN-09-35SN ideal for use in industrial manufacturing, military infrastructure, aerospace technology, and commercial applications that demand rugged and dependable circular connectors.
MIL-DTL-38999 Series III Class Z compliant for military-grade reliability. Black zinc nickel plating providing up to 500 hours salt spray resistance. 6 female contacts in copper alloy with gold plating to prevent corrosion.
Mount type: Wall mount with screw coupling and solder termination. Temperature range from -65°C to +175°C for extreme environment operation. Electrical ratings: 400-500 V AC voltage and 5 A current. Durable aluminium housing with black zinc nickel plating.
Up to 500 mating cycles ensuring long service life. Explore the full range of Mil Spec Circular Connectors from Amphenol Limited on EnvMart to find solutions for your demanding connectivity needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates under a voltage range of 400 to 500 volts AC.
This model has a current rating of 5 amperes.
It supports a temperature range from -65°C to 175°C, making it suitable for extreme environments.
The connector features 6 female contacts made of copper alloy.
It utilizes a solder termination type for secure connections.
The housing is made of aluminium with black zinc nickel plating for enhanced corrosion resistance.
This model is designed for wall mounting with a screw coupling mechanism.
It complies with the MIL-DTL-38999 Series III Class Z standards.
The contacts are plated with gold to ensure reliable conductivity and corrosion resistance.
It provides salt spray resistance for up to 500 hours, enhancing its durability in harsh environments.
This connector is capable of withstanding up to 500 mating cycles, ensuring longevity.
It is suitable for military, industrial, and aerospace applications requiring robust connectivity.
