Amphenol Limited MIL Spec Circular Connector Brass Straight 3 Way Flange Female Contacts Shell Size 8 62GB-12E08-98SN
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Amphenol Limited |
| Orientation | Straight |
| Current | 7.5A |
| Model | 62GB-12E08-98SN |
| Mount Type | Flange |
| Housing Material | Aluminium |
| Contact Material | Brass |
| Series | 62GB |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shell Size | 8 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Miniature |
| Shell Plating | Zinc Cobalt |
Key Features
- Compliant with MIL-DTL-26482 military standard for reliable performance.
- Constructed with an aluminium shell and brass contacts for durability.
- Features a straight orientation and bayonet mating type for secure connection.
- Operates safely between -55°C to 125°C, suitable for harsh environments.
- Gold plated contacts ensure excellent conductivity and corrosion resistance.
- Zinc cobalt plating on the shell offers high resistance to corrosion.
- Designed for miniature connector size with 3 female contacts for precision applications.
- Ideal for military, aerospace, industrial, and rugged electronic component applications.
Product Description
Amphenol Limited 62GB-12E08-98SN is a MIL Spec circular connector featuring a brass straight 3 way flange design with female contacts and a shell size of 8. This connector complies with the MIL-DTL-26482 military specification and offers dependable performance under demanding conditions.
The connector's body is machined from solid aluminium alloy and finished with a zinc cobalt plating that provides robust corrosion resistance. The solder bucket type connectors come with gold plated female brass contacts, enhancing conductivity and durability. The connector features a straight orientation with a bayonet type mating system that makes connections secure and prevents mismating with the integrated keyway.
The connector operates reliably within a wide temperature range of -55°C to 125°C, making it suitable for use in harsh environments, including military, industrial, aerospace, and rugged electronic applications where dependable circular connectors are required.
The 62GB series ensures a high degree of environmental protection when mated, and its miniaturized form factor allows use in space-constrained settings. This model is flange mounted for firm attachment to panels or equipment chassis.
Key features of the connector include its bayonet lock system for secure connection, gold plated contacts for corrosion resistance, and robust aluminium housing with zinc cobalt plating. It is manufactured in the United Kingdom, adhering to high-quality standards for military-grade components.
Compliant with MIL-DTL-26482 military standards. Aluminium shell with zinc cobalt olive drab finish for corrosion resistance. Gold plated brass female contacts for superior conductivity. Straight orientation and flange mount for secure panel attachment.
Bayonet mating type lock system for assured connection. Wide operating temperature range from -55°C to 125°C. Miniature connector size, shell size 8, with 3 female contacts. Prevents mismating with integrated keying system.
Suitable for military, aerospace, industrial, and demanding applications. Manufactured in the United Kingdom. Explore more Mil Spec Circular Connectors and high-quality Amphenol Limited products in the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates reliably within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
It features 3 female contacts made of brass, which are gold plated for enhanced conductivity and corrosion resistance.
The shell size of this connector is 8, designed for miniature applications.
This model is flange mounted, allowing for secure attachment to panels or equipment chassis.
It complies with the MIL-DTL-26482 military specification, ensuring reliable performance under demanding conditions.
The housing is made of aluminium with a zinc cobalt plating, while the contacts are made of brass and gold plated.
It utilizes a bayonet mating type, which provides a secure connection and prevents mismating through an integrated keyway.
The current rating for this model is 7.5A, suitable for various applications.
This connector is manufactured in the United Kingdom, adhering to high-quality standards for military-grade components.
The contacts in this model are of the solder termination type, allowing for secure electrical connections.
This model features 3 female contacts, designed for precision applications.
The gold plating on the contacts enhances conductivity and provides corrosion resistance, ensuring reliable performance.
