Weidmüller BL Series Pluggable Terminal Block, 5-Contact, 3.5 mm Pitch, 1 Row, 320 V, 17 A, Female Connector 1606670000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Orange |
| Orientation | 180° |
| Current | 17A |
| Depth | 18.5mm |
| Width | 24.5mm |
| Housing Material | Polybutylene Terephthalate |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 5 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 28mm² |
| Maximum Wire Size mm² | 14mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Clamping Yoke |
Key Features
- The housing is made of durable polybutylene terephthalate material.
- Features a clamping yoke screw system for secure wire connections.
- Supports wire sizes from 28 to 14 AWG (8 to 28 mm²).
- Designed with a 180° orientation for easy wiring installation.
- Colour coded in orange for clear identification.
- Ideal for PCB applications with vertical or horizontal headers.
- Provides easy wiring with yoke clamp connection for consistent performance.
- Complies with UL94 V-0 flammability standard for safety.
Product Description
Weidmüller 1606670000 Pluggable Terminal Block is a high-quality female connector designed for electrical and electronic applications requiring reliable termination and connection of wires. Featuring 5 contacts arranged in a single row with a compact 3.5 mm pitch, this terminal block supports currents up to 17 A and voltages up to 320 V, making it suitable for a wide range of industrial and commercial uses.
The housing is constructed from polybutylene terephthalate, providing excellent mechanical strength and resistance to heat. The clamping yoke screw mechanism ensures secure, vibration-resistant wire connections and facilitates easy installation and maintenance. This design supports wire sizes ranging from 28 AWG (0.08 mm²) to 14 AWG (2.5 mm²), accommodating various wiring requirements.
Its 180° wiring orientation enables straightforward horizontal wire outlets, improving accessibility in panel wiring setups. The terminal block is color-coded orange for easy identification, enhancing system organization. It is part of the Weidmüller BL series, known for durable and efficient pluggable terminal solutions widely used in industrial automation, control cabinets, HVAC systems, and power distribution modules.
The module complies with UL94 V-0 flammability class, guaranteeing enhanced safety against fire hazards. It is engineered with tin-plated copper alloy terminals for optimal conductivity and corrosion resistance, ensuring long-term reliability in demanding environments.
This terminal block is suitable for mounting on PCBs with the Weidmüller Omnimate range headers, which are available in both vertical and horizontal solderable types. Polarizing pins prevent improper connections, ensuring assembly accuracy. Corresponding flanged headers are available with stock numbers 762-6343 (180°) and 762-6303 (90°) to complete your connection system.
The housing material is polybutylene terephthalate ensuring durability. The terminal block includes 5 female contacts with a 3.5 mm pitch. Rated current is 17 A suitable for various electronic circuits. Wire connection is by clamping yoke type screw technology.
Wire size compatibility ranges from 28 AWG to 14 AWG. Designed for easy wiring with 180° orientation and orange color coding. Compliant with UL94 V-0 flammability classification for safety.
Weidmüller products are trusted in industrial, laboratory, manufacturing, and electrical installation applications. This BL Series Pluggable Terminal Block balances compact design with reliable electrical performance, making it ideal for PCB connectors and modular assembly.
Explore additional Weidmüller products and other pluggable terminal block solutions for enhanced connectivity at EnvMart.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block has a maximum current rating of 17 A.
The voltage rating for this terminal block is 320 V.
It supports wire sizes ranging from 28 AWG (0.08 mm²) to 14 AWG (2.5 mm²).
The contacts in this terminal block are arranged with a pitch of 3.5 mm.
The housing is made from polybutylene terephthalate, providing excellent mechanical strength and heat resistance.
It features a 180° wiring orientation, allowing for straightforward horizontal wire outlets.
This terminal block is color-coded in orange for clear identification.
It uses a clamping yoke screw connection method for secure wire connections.
This model features 5 female contacts.
Yes, it complies with the UL94 V-0 flammability standard for safety against fire hazards.
The dimensions of this terminal block are 24.5 mm in width and 18.5 mm in depth.
The country of origin for this terminal block is Germany.
