SMC Pneumatic Guided Cylinder 63mm Bore, MGP Series, 200 mm Stroke, Double Acting, Rubber Cushioning MGPM63TF-200Z
Specifications
| Country of Origin | China |
|---|---|
| Brand | SMC |
| Maximum Operating Pressure | 1 Mpa |
| Height | 112mm |
| Length | 318mm |
| Model | MGPM63TF-200Z |
| Gross Weight | 9.6kg |
| Width | 48mm |
| Series | MGP |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -10°C |
| Stroke Length | 200mm |
| Bore Diameter | 63mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Cushioning Type | Rubber Cushioning at Both Ends |
| Guide Type | Slide Bearing |
| Maximum Piston Speed | 500 mm/s |
| Piston Rod Thread Standard | G |
Key Features
- The 63mm bore size provides robust force for medium-duty pneumatic tasks.
- 200mm stroke length enables extended linear movement within a compact assembly.
- Rubber cushioning at both ends reduces impact during piston travel.
- Integrated slide bearing guide enhances lateral load capacity and stability.
- Supports a maximum operating pressure of 1 MPa for compatibility with common pneumatic systems.
- Operates reliably in temperature range from -10°C to 60°C for typical industrial environments.
- Single rod type with standard G thread for easy rod attachments and fittings.
- Maximum piston velocity of 500 mm/s for efficient high-speed cyclic operation.
Product Description
SMC MGPM63TF-200Z Pneumatic Guided Cylinder combines a 63mm bore and 200mm stroke with a robust double acting mechanism to deliver precise linear motion required in industrial automation.
This cylinder features rubber bumper cushioning at both ends to absorb impact shocks and minimize wear, enhancing durability and reliability in repetitive tasks. The integrated slide bearing guide provides superior lateral stability and load handling, suitable for factory automation where guided rod travel is essential.
Designed to operate within a temperature range of -10°C to 60°C, it accommodates typical indoor industrial conditions. The maximum operating pressure of 1 MPa and maximum piston speed of 500 mm/s assure compatibility with standard pneumatic systems and fast actuation cycles.
The single rod with G thread standard supports various end fittings and mounting configurations. Its compact size - 318mm length, 48mm width, and 112mm height - makes it ideal for installations with limited space.
The 63mm bore offers significant force suitable for medium-duty automation tasks. Double acting piston extends and retracts with full control for accurate positioning. Robust rubber cushioning at both ends minimizes operational shocks and noise.
Slide bearing guide mechanism improves lateral stability and reduces wear. Maximum 1 MPa operating pressure supports most pneumatic circuit requirements. Temperature operation range from -10°C to 60°C suitable for industrial environments.
Single rod design with G thread for versatile fitting options. Compact dimensions optimize integration in assembly lines and machine tools. Supports high-speed operation up to 500 mm/s for productivity enhancement.
This product is widely used in industrial applications such as pick-and-place systems, machine tool workpiece positioning, transfer systems requiring guided motion, clamping fixtures for repeatable strokes, and panel handling needing controlled cushioning. The reliable design and robust features ensure durability and efficiency in demanding automation settings.
EnvMart offers this cylinder to support industrial automation needs with precision, durability, and trusted brand quality.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The stroke length of this model is 200 mm, allowing for extended linear movement.
This cylinder features a bore diameter of 63 mm, providing robust force for medium-duty tasks.
It supports a maximum operating pressure of 1 MPa, making it compatible with common pneumatic systems.
The maximum piston speed is 500 mm/s, allowing for efficient high-speed cyclic operation.
It features rubber cushioning at both ends to reduce impact during piston travel and minimize wear.
The dimensions are 318 mm in length, 48 mm in width, and 112 mm in height.
It operates reliably within a temperature range of -10°C to 60°C, suitable for typical industrial environments.
This model uses a slide bearing guide, which enhances lateral load capacity and stability.
It features a single rod design, which supports various end fittings and mounting configurations.
It is widely used in applications such as pick-and-place systems, machine tool positioning, and clamping fixtures.
The action type is double acting, allowing for controlled extension and retraction of the piston.
The gross weight of this model is 9.6 kg, which is important for installation considerations.
