SMC Pneumatic Guided Cylinder 32mm Bore, MGP Series, 125mm Stroke, Double Acting MGPM32TF-125Z

SMC MGPM32TF-125Z Pneumatic Guided Cylinder - MGP Series, featuring a 32mm bore and 125mm stroke length, provides highly controlled double acting linear actuation for diverse industrial applications.

This compact Pneumatic Guided Cylinder is engineered to offer precise lateral stability and repeatable positioning, using a slide bearing guide to reduce lateral play. The cylinder offers smooth, guided thrust ideal for automation tasks including pick-and-place stations, press-fit operations, and component alignment in electronics manufacturing.

The double acting mechanism allows for independent extension and retraction, while rubber cushioning at both ends reduces noise and impact stress during end-of-stroke movements. Rated for maximum operating pressure of 1 MPa, it supports higher pneumatic loads required in demanding industrial environments.

Designed to operate reliably between -10°C and 60°C, the cylinder is well-suited for typical factory and assembly plant climates. Its maximum piston speed of 500 mm/s allows rapid cycle times in short stroke applications.

The unit includes a single rod with a G thread standard, facilitating straightforward integration with various tooling setups. Its compact size, with width 48mm, height 112mm, length 227mm, and lightweight design of 3.2 kg, makes it ideal for space-constrained installations.

The 32mm bore delivers consistent force for system design calculations. 125mm stroke ensures suitable travel distance within a compact form factor. Double acting pneumatic drive provides precise movement control. Slide bearing guide enhances positioning accuracy by minimizing lateral play.

Rubber bumpers cushion impacts, reducing wear and noise. Maximum operating pressure of 1 MPa supports industrial pneumatic loads. Operating temperature range -10°C to 60°C covers most indoor applications. Supports piston speeds up to 500 mm/s for efficient automation cycles.

Single rod with G thread allows secure connection to tooling components. Compact physical dimensions and moderate weight promote flexible machine integration.

Applications include use in pick-and-place stations needing guided travel, press-fit operations requiring lateral stability, component alignment in electronics assembly, ejector or transfer mechanisms in automation, and fixtures demanding cushioned impact control.

SMC pneumatically powered guided cylinders are widely used across industrial, manufacturing, electronics assembly, and automation fields. Explore a broad range of pneumatic cylinders and related fluid power equipment in the EnvMart catalog for your application needs.
