Microchip 1-Channel Low Dropout Voltage Regulator 100mA 1.8V SOT-23 5-Pin TC1015

Microchip TC1015 is a 1-Channel Low Dropout (LDO) Voltage Regulator designed to provide a fixed output voltage of 1.8V at up to 100mA load current. It comes in a compact SOT-23 5-Pin surface mount package, making it suitable for space-constrained electronic designs. The device operates with positive polarity and features a low dropout voltage, minimizing power loss and enhancing energy efficiency.

The regulator is characterized by a low quiescent current of 50µA, supporting battery-powered and low power consumption circuits. It supports a wide input voltage range from 2.7V to 6V and temperature operation spanning from -40°C to 125°C, making it ideal for industrial, consumer electronics, and embedded system applications.

Precisely engineered for reliable power management, it boasts line regulation of 0.05% and load regulation of 0.5%, ensuring stable and consistent voltage output under varying load and input conditions. Its fixed output type ensures simple design with minimal external components.

The SOT-23 package dimensions are 3.1mm length, 1.8mm width, and 1.3mm height, facilitating integration into densely packed printed circuit boards and automated manufacturing processes.

This voltage regulator is not specifically certified to automotive standards but is well-suited for typical electronics manufacturing, industrial controls, instrumentation, communication devices, and laboratory equipment.

Designed for positive polarity with low dropout voltage operation. Offers low quiescent current of 50µA ensuring energy-efficient performance. Output current capability up to 100mA for versatile power management. Wide input voltage range from 2.7V to 6V suitable for various applications.

Operates efficiently over -40°C to 125°C temperature range. Compact dimensions: 3.1mm length, 1.8mm width, and 1.3mm height ensuring space-saving PCB designs. Surface mount type package ideal for automated assembly processes.

Fixed output voltage regulator without switching, ensuring stable voltage supply. No automotive standard compliance, designed for general industrial and electronic applications. Reliable line regulation of 0.05% and load regulation of 0.5% for consistent output voltage.

This versatile Microchip TC1015 LDO voltage regulator supports industrial, consumer electronics, measurement instruments, communication devices, and general embedded systems where reliable low voltage power regulation is required. Explore our Electronics & Electricals category for more semiconductor and power management ICs.
