MEAN WELL IP67 1 Output LED Driver, 15V, 172.5W, 11.5A, 1 to 10 V PWM Resistance Dimming

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP67 1 Output LED Driver, 15V, 172.5W, 11.5A, 1 to 10 V PWM Resistance Dimming

Name: MEAN WELL IP67 1 Output LED Driver, 15V, 172.5W, 11.5A, 1 to 10 V PWM Resistance Dimming
Brand: MEAN WELL
SKU: 128561
Price: 20.22 USD
Availability: InStock



Category LED Driver Brand MEAN WELL Condition New

Specifications

Country of Origin	Taiwan
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Panel
Series	HLG-185H
Configuration	Encapsulated
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	172.5W
Input Voltage	264, 90, 127, 370V ac
Output Voltage	15V
Power Dissipation	172W
Standards/Approvals	CE, EN, TUV, UL
Dimming Operation	1 to 10 V PWM Resistance
Primary Type	AC-DC
Driver Current	11.5A

Key Features

Encapsulated IP67 rated power supply suitable for dry, damp, or wet indoor and outdoor locations.
Designed for LED lighting and moving sign applications requiring high reliability and long life.
Constant current adjustable through output cable using 1-10Vdc or 10V PWM signal or resistor.
Protection features include short circuit, overload, overvoltage, and over temperature safeguards.
Compliance with CE, EN, TUV, and UL safety and EMC standards for LED drivers.
Power factor correction to EN 61000-3-2 and EMC compliance to EN 55022 Class B.
Rated for panel mounting with AC-DC primary type and encapsulated configuration.

Product Description

MEAN WELL HLG-185H-15B is a high-efficiency, encapsulated LED driver offering a single output of 15V and a maximum output power of 172.5 watts with a driver current of 11.5A. It operates in constant voltage mode and supports dimming via 1 to 10 V PWM resistance for precise brightness control. The driver is IP67 rated, making it suitable for use in dry, damp, or wet environments, both indoors and outdoors.

This LED driver is designed for LED lighting applications including moving signs that demand long life, high efficiency, and robust protection features. Safety and compliance standards such as CE, EN, TUV, and UL certifications ensure it meets worldwide lighting safety requirements. It supports multiple input voltages including 90V, 127V, 264V, and 370V AC ranges.

The product features extensive protection mechanisms including short circuit, overload, overvoltage, and over temperature protection. It includes a 300mm un-terminated input lead (3-core 18AWG), output lead (2-core 14AWG), and dimming lead (2-core 18AWG) for easy installation and customized wiring. Power factor correction and EMC compliance further enhance reliability and performance.

Its panel mount design and encapsulated construction provide durability and flexibility for various industrial, commercial, and architectural LED lighting solutions. The HLG-185H series is well suited for applications demanding waterproof and dimmable power supplies operating in challenging environmental conditions.

Encapsulated IP67 rated power supply suitable for dry, damp, or wet indoor and outdoor locations. Compatible with LED lighting and moving sign applications demanding high reliability. Constant current level adjustable through output cable with 1-10Vdc or 10V PWM signal or resistor.

Short circuit, over load, over voltage and over temperature protections included. Wide input voltage range including 90V, 127V, 264V, and 370V AC. Compliance with CE, EN, TUV, UL, and EMC EN 55022 Class B standards. Power factor correction compliant with EN 61000-3-2.

Includes 300mm un-terminated input, output, and dimming leads for flexible connection.

This MEAN WELL LED Driver is ideal for industrial, commercial, and outdoor LED lighting uses requiring reliable, waterproof, and dimmable power solutions. Explore MEAN WELL and related LED Driver products at EnvMart for your specific lighting needs.
