RS PRO Power Relay PCB Mount 12V DC Coil 16A Switching Current SPST 476-804
Specifications
| Country of Origin | China |
|---|---|
| Brand | RS PRO |
| Height | 20.6mm |
| Length | 21mm |
| Model | 476-804 |
| Width | 16mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 16A |
| Terminal type | Through Hole |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 400Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 400V ac |
| Coil Power | 360mW |
| High switching current capability | up to 20A |
Key Features
- The relay supports a high switching current capability of up to 20A.
- Features through-hole terminal type for secure PCB mounting.
- Coil resistance is 400 ohms with a power consumption of 360mW.
- Operational temperature range from -40°C to 85°C ensures reliability in varied environments.
- Silver alloy contact material ensures low contact resistance of 100 milliohms.
- Meets RoHS standards and has IEC 60335-1 certification.
- Designed for both DC and AC switching with DC voltage up to 30V and AC voltage up to 400V.
- Features a fully sealed wash tight construction with surge voltage capacity up to 6kV.
Product Description
RS PRO 476-804 power relay is a high-performance PCB mount relay featuring a 12V DC coil and SPST contact configuration, capable of switching currents up to 16A.
This fully sealed, wash tight relay is designed to provide high switching current capability up to 20A, making it suitable for industrial and electronic applications where reliable power switching is critical.
The relay comes with a coil resistance of 400 ohms and a coil power consumption of 360mW, operating efficiently over a wide temperature range from -40°C to 85°C.
Constructed with silver alloy contacts, it ensures low contact resistance of 100 milliohms for optimal electrical performance. It supports switching DC voltages up to 30V and AC voltages up to 400V, compliant with IEC 60335-1 and RoHS standards.
With physical dimensions of 21mm length, 16mm width, and 20.6mm height, and through-hole terminals, it facilitates secure PCB mounting in compact devices. This relay also withstands surge voltages up to 6kV between coil and contacts, providing durability against electrical transients and spikes.
The relay supports a high switching current capability of up to 20A. Features through-hole terminal type for secure PCB mounting. Coil resistance is 400 ohms with a power consumption of 360mW. Operational temperature range from -40°C to 85°C ensures reliability in varied environments.
Silver alloy contact material ensures low contact resistance of 100 milliohms. Compact dimensions support integration in space-constrained equipment. Meets RoHS standards and IEC 60335-1 certification. Designed for DC and AC switching applications with voltages up to 30V DC and 400V AC.
Fully sealed construction enhances durability and wash tight properties.
This power relay is ideal for applications in electronics, automation, industrial control systems, household appliances, and other sectors requiring reliable power switching solutions.
Explore more high-quality relays and electrical components in the Electronics & Electricals category at EnvMart.
Explore more products in our Power Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This power relay can handle a maximum switching current of 16A, with a high switching current capability of up to 20A.
The relay has dimensions of 21mm in length, 16mm in width, and 20.6mm in height.
It operates with a coil voltage of 12V DC and has a coil resistance of 400 ohms.
The relay operates efficiently within a temperature range of -40°C to 85°C.
The relay features silver alloy contacts, which ensure low contact resistance of 100 milliohms.
It supports switching DC voltages up to 30V and AC voltages up to 400V.
This model utilizes a PCB mount with through-hole terminals for secure installation.
The coil power consumption for this relay is 360mW.
Yes, it meets RoHS standards and has IEC 60335-1 certification.
The relay can withstand surge voltages up to 6kV between the coil and contacts.
It is designed for use in electronics, automation, industrial control systems, and household appliances.
This relay features a Single Pole Single Throw (SPST) contact configuration.
