ABB System Pro M Compact S200 Miniature Circuit Breaker 4-Pole 500mA Type D 440V AC 12V 2CDS254001R0981 S204 D 0.5A - 10 KA
Specifications
| Country of Origin | Germany |
|---|---|
| Range | System Pro M Compact |
| Brand | ABB |
| Height | 88mm |
| Model | 2CDS254001R0981 S204 D 0.5A - 10 KA |
| Depth | 69mm |
| IP Rating | IP20 |
| Width | 70mm |
| Mount Type | DIN Rail |
| Current Rating | 500mA |
| Series | S200 |
| Ambient air temperature | Operation -25 to +55 °C, Storage -40 to +70 °C |
| Terminal type | Screw |
| Breaking Capacity | 6kA |
| Number of Poles | 4 |
| Standards/Approvals | UL1077, IEC/EN 60947-2, IEC/EN 60898-1 |
| Rated AC Voltage | 440V ac |
| Rated DC Voltage | 12V dc |
| Tripping Characteristics | Type D |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Electromechanic, Thermal |
Key Features
- Rated AC voltage of 440V ac and DC voltage of 12V dc ensure versatility.
- Mounts easily on DIN rail for secure installation.
- Provides breaking capacity of 6 kA to handle high fault currents.
- Features screw-type terminals for reliable electrical connections.
- Equipped with electromechanic, thermal tripping mechanism for overload and short circuit protection.
- Compact dimensions of 88mm height, 70mm width, and 69mm depth save panel space.
- Complies with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077 standards.
- IP20 rated for protection against solid objects.
Product Description
ABB 2CDS254001R0981 S204 D 0.5A - 10 KA System Pro M Compact S200 miniature circuit breaker is a high-performance electrical device designed for industrial, commercial, and residential electrical distribution systems. It ensures protection of electrical circuits from overloads and short circuits via its electromechanic and thermal tripping mechanisms.
This 4-pole device supports a rated AC voltage of 440V and DC voltage of 12V, making it suitable for both AC and DC applications. It offers a current rating of 500mA and a breaking capacity of 6 kA, which allows it to handle fault currents effectively without damage.
Mounting on a DIN rail, the breaker is easy to install and maintain. Screw terminals provide secure electrical connections. Its compact size (88mm height, 70mm width, 69mm depth) allows use in space-constrained panels. The breaker is IP20 rated, protecting against solid ingress while enabling adequate ventilation.
Compliant with international standards IEC/EN 60947-2, IEC/EN 60898-1, and UL1077, this device guarantees safety and reliability. It operates efficiently across ambient temperatures from -25 to +55 °C, with storage range down to -40 °C.
Rated 440V AC and 12V DC for versatile electrical systems. Type D tripping characteristic suited for motors and inductive loads. 6 kA breaking capacity for effective fault current interruption. Electromechanic and thermal trip for overload and short circuit protection.
Compact DIN rail mounting design. Complies with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077 standards. IP20 protection rating ensuring safety against solid ingress. Designed for disassembly promoting sustainability.
This Miniature Circuit Breaker is ideal for industrial automation, electrical panels, manufacturing setups, construction sites, and facility maintenance, providing reliable protection and compliance with electrical safety regulations.
Explore the wide selection of circuit breakers and electrical components in the Electronics & Electricals category at EnvMart for quality and trusted solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This miniature circuit breaker has a rated AC voltage of 440V and a rated DC voltage of 12V, making it suitable for both AC and DC applications.
It offers a breaking capacity of 6 kA, allowing it to effectively handle high fault currents without damage.
The dimensions are 88mm in height, 70mm in width, and 69mm in depth, making it compact for installation in space-constrained panels.
This model is designed for DIN rail mounting, which facilitates easy installation and maintenance.
The current rating for this circuit breaker is 500mA, suitable for various electrical applications.
It features a Type D tripping characteristic, which is particularly suited for motors and inductive loads.
The circuit breaker has an IP20 rating, providing protection against solid objects while allowing for adequate ventilation.
It complies with international standards including IEC/EN 60898-1, IEC/EN 60947-2, and UL1077, ensuring safety and reliability.
It operates efficiently across ambient temperatures from -25 to +55 °C, with a storage range of -40 to +70 °C.
It is equipped with screw-type terminals, ensuring reliable electrical connections.
The device utilizes electromechanic and thermal tripping mechanisms for overload and short circuit protection.
This miniature circuit breaker is manufactured in Germany.
