ABB Molded Case Circuit Breaker 4-Pole 160A 690V AC Breaking Capacity 100 kA XT2H 1SDA067901R1
Specifications
| Country of Origin | Italy |
|---|---|
| Range | XT2H |
| Brand | ABB |
| Height | 130mm |
| Model | XT2H |
| Depth | 82.5mm |
| Width | 120mm |
| Mount Type | Fixed |
| Current Rating | 160A |
| Series | 1SDA06 |
| Terminal type | Fixed |
| Breaking Capacity | 100kA |
| Number of Poles | 4 |
| Standards/Approvals | CE, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Solid State |
| Reset Actuator Type | Lever |
Key Features
- Designed with a fixed mount type and fixed terminals for secure installation.
- Features solid state tripping mechanism ensuring precise circuit interruption.
- Complies with CE, IEC, and RoHS standards for quality and safety.
- Equipped with a lever reset actuator for easy operation.
- Rated insulation voltage of 1000 V ensures durability under operational conditions.
- Manufactured in Italy, reflecting high-quality engineering and reliability.
Product Description
ABB XT2H 1SDA067901R1 Molded Case Circuit Breaker is a high-performance 4-pole fixed circuit breaker with a current rating of 160A, designed for industrial, automation, and electrical applications. It supports a rated operational AC voltage of 690V and insulation voltage of 1000V (Ui), offering robust protection against overloads and short circuits.
The device incorporates a solid state release with an Ekip I tripping mechanism for accurate and responsive circuit interruption. Its fixed terminal design ensures reliable and safe connections, suitable for critical electrical installations.
Dimensions of 130mm height, 120mm width, and 82.5mm depth allow for compact panel mounting while maintaining high breaking capacity of 100 kA, enabling it to handle substantial fault currents efficiently.
Certified to CE, IEC, and RoHS compliance standards, the breaker is built with sustainability in mind and designed for disassembly. The lever-type reset actuator facilitates easy manual resets, adding to operational convenience.
This ABB Molded Case Circuit Breaker is ideal for use in industrial plants, electrical distribution boards, manufacturing facilities, and HVAC systems where high current protection and reliable switching are essential.
Designed with a fixed mount and fixed terminals for stable installation. Solid state tripping mechanism ensures dependable circuit protection. Conforms to international CE, IEC, and RoHS safety and environmental standards.
Compact form factor with precise mechanical dimensions for space efficiency. Manufactured in Italy, assuring premium quality and durability. Explore the full range of ABB Circuit Breakers and electrical components on EnvMart to find reliable solutions for your industrial and commercial electrical protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This molded case circuit breaker has a current rating of 160A, making it suitable for high-performance industrial applications.
The breaking capacity of this model is 100 kA, allowing it to efficiently handle substantial fault currents.
It supports a rated operational AC voltage of 690V, which is essential for various electrical applications.
This unit features a 4-pole configuration, providing comprehensive protection in multi-phase systems.
It incorporates a solid state release with an Ekip I tripping mechanism for accurate and responsive circuit interruption.
The dimensions are 130mm in height, 120mm in width, and 82.5mm in depth, allowing for compact panel mounting.
It complies with CE, IEC, and RoHS standards, ensuring quality and safety in its design and manufacturing.
This model is designed for fixed mounting with fixed terminals, ensuring secure and reliable installation.
It features a lever-type reset actuator, which allows for easy manual resets during operation.
It is manufactured in Italy, reflecting high-quality engineering and reliability in its construction.
It is ideal for use in industrial plants, electrical distribution boards, manufacturing facilities, and HVAC systems where high current protection is essential.
The rated insulation voltage is 1000V, ensuring durability under operational conditions.
