ABB Molded Case Circuit Breaker 4-Pole 160A 200 kA Breaking Capacity Fixed Mount XT2V 1SDA06 1SDA068172R1

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 160A 200 kA Breaking Capacity Fixed Mount XT2V 1SDA06 1SDA068172R1



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT2V
Brand	ABB
Height	130mm
Model	XT2V
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	160A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	200kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Reset Actuator Type	Lever
Short circuit performance level	V

Key Features

Rated current of 160 amperes for continuous operation.
Breaking capacity of 200 kiloamperes ensuring robust short circuit protection.
Four-pole design compatible with three-phase systems plus neutral.
Rated AC voltage of 690 volts and DC voltage of 500 volts maximum.
Fixed terminal type with lever reset actuator for ease of operation.
Compliant with CE, IEC, and RoHS standards for safety and environmental requirements.
Compact dimensions measuring 130mm height, 120mm width, and 82.5mm depth.
Designed for disassembly in line with sustainable product engineering.

Product Description

ABB XT2V 1SDA06 Molded Case Circuit Breaker 4-Pole with 160A current rating and 200 kA breaking capacity is engineered for industrial and commercial electrical protection applications. Rated for 690V AC and 500V DC, it provides stable and reliable power interruption performance.

The breaker features a fixed mounting type with front terminals and lever reset actuator, simplifying installation and maintenance. It complies with CE, IEC, and RoHS standards, highlighting ABB's commitment to safety and environmentally responsible manufacturing.

Dimensionally compact, the breaker measures 130 mm in height, 120 mm in width, and 82.5 mm in depth, suitable for space-constrained electrical panels. It supports electrical durability of 120 cycles per hour and a rated insulation voltage of 1000 V (Ui).

This molded case circuit breaker is designed for sustainability with a claim for easy disassembly under the Better World program. It is manufactured in Italy, reflecting stringent quality controls and design excellence.

Rated current of 160 amperes for continuous operation. Breaking capacity of 200 kiloamperes ensuring robust short circuit protection. Four-pole fixed mounting design for three-phase plus neutral coverage. Rated AC and DC voltages of 690 V and 500 V respectively.

Reliable mechanical operation with lever reset actuator type. Compliance with international safety and environmental standards CE, IEC, RoHS. Compact dimensions: 130 mm height, 120 mm width, 82.5 mm depth. Electrical durability supports 120 cycles per hour reliability.

Better World product designed for disassembly and sustainability. Manufactured in Italy under stringent quality controls.

This ABB XT2V molded case circuit breaker is ideal for industrial, commercial, manufacturing, and electrical distribution applications requiring high fault breaking capacity and durable performance. It provides dependable protection against short circuits and overloads in power systems.
