ABB Tmax XT Molded Case Circuit Breaker 3-Pole 63A 690V AC 100 kA Breaking Capacity 1SDA067926R1 XT2L 160 Ekip LSI 63A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 63A 690V AC 100 kA Breaking Capacity 1SDA067926R1 XT2L 160 Ekip LSI 63A FF



Category Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067926R1 XT2L 160 Ekip LSI 63A FF
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	63A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	100kA
Number of Poles	3
Standards/Approvals	RoHS, CE, IEC
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Rated current (In)	63 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Designed for fixed mounting with fixed terminals ensuring secure installation.
Rated AC voltage of 690 volts suitable for high voltage applications.
Breaking capacity of 100 kA to safely interrupt high fault currents.
Incorporates solid state Ekip LSI tripping mechanism for precise protection.
Equipped with lever reset actuator for easy manual operation.
Complies with RoHS, CE, and IEC standards assuring quality and safety.
Rated frequency supports 50/60 Hz networks for versatile use.
Impulse withstand voltage rating of 8 kV for transient surge protection.

Product Description

ABB's 1SDA067926R1 XT2L 160 Ekip LSI 63A FF Molded Case Circuit Breaker in the Tmax XT range provides industrial-grade protection for electrical circuits up to 63 amperes with a 3-pole configuration. Designed for fixed installation with fixed terminals, it operates at a rated AC voltage of 690 volts and interrupts fault currents up to 100 kiloamperes, ensuring system safety and reliability.

The breaker uses a solid state tripping mechanism known as Ekip LSI, combining overload, short-circuit, and leakage current protection for comprehensive safeguarding of electrical equipment. The lever-type reset actuator facilitates straightforward manual resetting after fault clearance. It complies with international standards including RoHS, CE, and IEC, confirming its quality and suitability for global applications.

Its compact size with dimensions of 120 mm width, 130 mm height, and 82.5 mm depth allows for efficient panel integration in industrial, commercial, and manufacturing environments. Rated for 50/60 Hz frequency use and with a rated impulse withstand voltage of 8 kV, it is designed to endure transient surges often encountered in electrical systems.

Manufactured in Italy, this breaker aligns with ABB's commitment to environmental sustainability by featuring a design for disassembly, facilitating recycling and maintenance. Ideal applications include electrical distribution panels, motor protection circuits, and automation systems across the electrical, industrial, and manufacturing sectors.

Fixed mounting with front terminals for secure electrical connections. Reliable 3-pole 63A rated current breaker for multi-phase load protection. High breaking capacity of 100 kiloamperes for fault interruption. Solid state Ekip LSI release for precise and versatile protection.

Lever reset actuator allows safe manual reset post-fault. Conforms to RoHS, CE, and IEC standards ensuring high quality and compliance. Compact dimensions facilitating space-efficient installation. Supports 50/60 Hz frequency grids.

Impulse withstand voltage rating of 8 kV protects against voltage spikes. Explore more ABB Circuit Breakers and industrial electrical protection devices on EnvMart for reliable and certified electrical products.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The breaking capacity of this molded case circuit breaker is 100 kA, allowing it to safely interrupt high fault currents.

It operates at a rated AC voltage of 690 volts, making it suitable for high voltage applications.

This model features a 3-pole configuration, providing multi-phase load protection.

It incorporates a solid state Ekip LSI tripping mechanism, which provides overload, short-circuit, and leakage current protection.

The dimensions are 120 mm in width, 130 mm in height, and 82.5 mm in depth, allowing for efficient panel integration.

This circuit breaker supports a rated frequency of 50/60 Hz, making it versatile for various applications.

It is equipped with a lever reset actuator for easy manual operation after a fault has been cleared.

Yes, it complies with RoHS, CE, and IEC standards, ensuring its quality and safety for global applications.

It is manufactured in Italy, aligning with ABB's commitment to quality and environmental sustainability.

The rated impulse withstand voltage is 8 kV, providing protection against transient surges.

This model is designed for fixed mounting with fixed terminals, ensuring secure installation.

It is suitable for applications including electrical distribution panels, motor protection circuits, and automation systems in industrial and commercial settings.
