ABB Tmax XT Molded Case Circuit Breaker 3-Pole 100A 690V AC 500V DC Breaking Capacity 36kA Thermal Magnetic Tripping XT1N

ABB XT1N Molded Case Circuit Breaker is a 3-pole device rated at 100A current with a breaking capacity of 36 kA, designed to provide robust electrical protection. It employs a thermal magnetic tripping mechanism that quickly responds to overloads and short circuits, with an opening time of approximately 15 milliseconds to minimize damage to connected equipment.

This MCCB operates reliably with an AC voltage rating of 690V and DC voltage of 500V, making it versatile for use in alternating and direct current circuits in various industrial, commercial, and energy management applications.

The compact frame size measures 130mm width, 130mm height, and 70mm depth, allowing efficient installation on DIN rails within switchgear enclosures and distribution boards. The front terminal design and toggle switch with red and green indicators allow easy installation and operation status identification.

The switch’s mechanical durability is rated for 25,000 operations, ensuring long-term reliability. Additionally, the included test button facilitates regular operational checks to maintain safety standards.

Typical applications include power distribution systems, motor and generator protection, industrial machines, and energy management installations. Its robust construction ensures stable performance in demanding environments.

Provides a breaking capacity of 36 kA suitable for high power applications. Rated for up to 690V AC and 500V DC voltage, supporting diverse circuits. Compact design with dimensions of 130mm (W) x 130mm (H) x 70mm (D) for space-efficient installation.

Supports DIN rail mounting suitable for switchgear panels and distribution boards. Equipped with front terminals and toggle switch with clear red and green indicators. Mechanical durability rated for 25,000 operations ensuring long service life.

Includes a test button to verify proper functioning and safety performance. Protects motors, generators, power distribution, and industrial machines from overloads and short circuits.

Explore the full range of ABB circuit protection devices for industrial and commercial applications on EnvMart, your reliable source for electrical components and automation solutions.
