Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header, 1 Contact, 2.54 mm Pitch 77311-124-01LF

Amphenol Communications Solutions 77311-124-01LF Vertical Through Hole Pin Header is designed to provide robust and reliable interconnect solutions in electronic assemblies. Featuring a single contact with a 2.54 mm pitch and a single row configuration, this connector is well-suited for board-to-board, wire-to-board, and cable-to-board applications.

The header housing is made from high-temperature thermoplastic, making it capable of withstanding solder reflow processes and providing mechanical stability in demanding environments. The contacts are constructed of phosphor bronze and plated with the same material to ensure excellent electrical conductivity and resistance to corrosion.

With a current rating of 3A and voltage rating up to 1500V, this header supports a wide range of power levels for various electronic systems. Its operating temperature range from -65°C to 130°C enables use in both industrial and commercial settings, where temperature extremes are common.

The unshrouded, vertical mount profile offers flexibility, especially in mezzanine stack applications, allowing mating from the top or bottom. The solder tail pin length of 2.9 mm and mating pin length of 6.75 mm ensure secure and reliable connections during assembly and operation.

This product carries UL approval (E66906), underscoring its compliance with international safety standards. Manufactured in France, it aligns with high-quality production standards expected in industrial electronics components.

The header features a single row with 1 contact for precise connectivity. It utilizes a 2.54 mm spacing pitch suitable for standard PCB layouts. Constructed with thermoplastic housing material rated for high temperature endurance.

Contact material is phosphor bronze with phosphor bronze plating for durability and conductivity. Designed with through hole mount type ensuring secure soldering and mechanical strength. Supports a maximum current rating of 3A and voltage rating up to 1500V.

Operating temperature range spans from -65°C to 130°C for versatile environmental performance. Unshrouded, vertical orientation improves accessibility and provides flexibility in mezzanine applications. UL approved component ensuring industry compliance under approval number E66906.

Manufactured in France, guaranteeing quality standards.

This vertical through hole pin header is ideal for use in industrial electronic designs, communication devices, telecommunications, and other applications requiring durable and reliable PCB connectors. It is suitable for manufacturing environments demanding high-quality board-to-board connections with assured performance.
