TE Connectivity PCB Non-Latching Relay 277V AC Coil 10A Switching Current 1-1721150-0
Specifications
| Country of Origin | China |
|---|---|
| Brand | TE Connectivity |
| Height | 15mm |
| Length | 20mm |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ORWH |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | Solder |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS, UL |
| Coil Resistance | 70Ω |
| Coil Voltage | 277V ac |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 360mW |
Key Features
- This relay features a compact PCB mount design suitable for embedded electronics.
- Operates reliably across a temperature range from -40°C to 85°C.
- Equipped with silver alloy contacts ensuring low resistance of 50mΩ.
- Supports switching up to 250V AC and 30V DC with a coil resistance of 70Ω.
- Coil power consumption is low at 360mW for energy-efficient operation.
- Offers solder terminal type for secure connections on the PCB.
- Compliance with RoHS and UL standards ensures safety and environmental adherence.
- Mechanical dimensions are 20mm length, 15mm height, and 10mm width for easy PCB integration.
Product Description
TE Connectivity 1-1721150-0 PCB Non-Latching Relay features a 277V AC coil and 10A switching capacity, ideal for various industrial and commercial control applications, including HVAC, appliances, and emergency lighting systems. Its compact PCB mount form factor with solder terminals facilitates easy integration into circuit boards.
The relay operates efficiently within a temperature range of -40°C to 85°C, making it suited for demanding environmental conditions. It has a coil resistance of 70Ω and coil power consumption of 360mW, contributing to low energy use.
Contact materials are silver alloy with a contact resistance of 50mΩ, ensuring high reliability and minimal loss during switching operations. The relay supports switching voltages up to 250V AC and 30V DC, catering to a wide range of electronic and electrical load requirements.
Certified to meet RoHS and UL standards, this relay conforms to environmental and safety regulations prevalent in industrial contexts. The dimensions of 20mm length, 15mm height, and 10mm width allow for a compact design footprint on PCBs.
This relay features a compact PCB mount design suitable for embedded electronics. Operates reliably across a temperature range from -40°C to 85°C. Equipped with silver alloy contacts ensuring low resistance of 50mΩ. Supports switching up to 250V AC and 30V DC with a coil resistance of 70Ω.
Coil power consumption is low at 360mW for energy-efficient operation. Offers solder terminal type for secure connections on the PCB. Compliance with RoHS and UL standards ensures safety and environmental adherence. Mechanical dimensions are 20mm length, 15mm height, and 10mm width for easy PCB integration.
Designed for appliances, emergency lighting, and HVAC systems requiring reliable power relays. This product is essential for industrial, laboratory, and commercial electrical control systems that demand durable, reliable switching components.
Explore more Power Relays and TE Connectivity products on EnvMart for comprehensive electrical control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This relay supports a maximum switching current of 10A.
The coil voltage rating for this model is 277V AC.
It operates reliably across a temperature range from -40°C to 85°C.
The relay has dimensions of 20mm in length, 15mm in height, and 10mm in width.
It features solder terminals for secure connections on the PCB.
The contact material is silver alloy, which ensures low contact resistance.
The contact resistance is 50mΩ, ensuring minimal loss during switching operations.
It supports switching voltages up to 250V AC and 30V DC.
The coil resistance is 70Ω.
The coil power consumption is low at 360mW, contributing to energy-efficient operation.
Yes, it complies with RoHS and UL standards, ensuring safety and environmental adherence.
This relay is suitable for various industrial and commercial control applications, including HVAC, appliances, and emergency lighting systems.
