SMC Pneumatic Guided Cylinder 16mm Bore, CQM Series, 10mm Stroke, Double Acting, Aluminium Alloy Body CDQMB16-10
Specifications
| Country of Origin | France |
|---|---|
| Brand | SMC |
| Body Material | Aluminium Alloy |
| Maximum Operating Pressure | 1 Mpa |
| Height | 29mm |
| Length | 41.5mm |
| Model | CDQMB16-10 |
| Gross Weight | 67g |
| Width | 29mm |
| Mount Type | Through Hole |
| Series | CQM |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -10°C |
| Stroke Length | 10mm |
| Bore Diameter | 16mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Cushioning Type | Rubber |
| Guide Type | Slide Bearing |
Key Features
- Compact and robust aluminium alloy body enhances durability and corrosion resistance.
- Double acting cylinder with magnetic piston for reliable performance.
- Maximum operating pressure of 1 MPa ensures suitability for demanding industrial applications.
- Through hole mount type facilitates easy installation and flexible mounting options.
- Slide bearing guide type provides smooth lateral load resistance and stability.
- Operates reliably within a temperature range of -10°C to 70°C for versatile environmental conditions.
- Maximum piston speed of 500mm/s supports high-speed actuation tasks.
- Includes rubber cushioning to reduce impact and extend service life.
Product Description
SMC CDQMB16-10 Pneumatic Guided Cylinder is a compact and reliable actuator in the CQM series engineered for controlled pneumatic motion in industrial automation, manufacturing, and fluid power applications. This double acting cylinder features a 16mm bore diameter and a 10mm stroke length, delivering precise linear motion with robust construction.
The aluminium alloy body is hard anodized to provide excellent corrosion resistance and strength while keeping the unit lightweight. Its guided rod design accommodates direct loads and enhances lateral load resistance between two and four times that of standard CQ series cylinders, ensuring stability in dynamic environments.
The cylinder employs a single rod type with slide bearing guide, allowing smooth movement and effective alignment. The through hole mounting type facilitates flexible and secure attachment to various machine assemblies.
Key functional benefits include a maximum operating pressure of 1 MPa and a maximum piston speed of 500mm/s, making it suitable for fast pneumatic actuation tasks. The unit includes rubber cushioning to safely absorb shocks and reduce noise during operation.
Designed to operate in temperatures from -10°C up to 70°C, this cylinder supports deployment in diverse industrial and environmental conditions. It features a non-rotatable magnetic piston, enhancing reliability and performance consistency.
The compact dimensions of 41.5mm length, 29mm width, and 29mm height allow integration into tight spaces without compromising mechanical strength. Compact and robust aluminium alloy construction. Double acting mechanism with magnetic piston standard.
High lateral load resistance with guided rod design. Through hole mount for versatile installation. Slide bearing guide type for smooth operation. Operating temperature range: -10°C to 70°C. Maximum operating pressure: 1 MPa.
Maximum piston speed: 500mm/second. Rubber cushioning reduces impact noise and wear.
Ideal for use in industrial tools, manufacturing automation, laboratory automation, and pneumatic actuator systems, the SMC CDQMB16-10 cylinder delivers dependable performance in precise motion control tasks. Please explore other pneumatic guided cylinders in the SMC CQM series for varying bore sizes and stroke lengths tailored to specific applications.
Discover more pneumatic cylinders and industrial automation components at EnvMart's Pneumatic Guided Cylinder category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The bore diameter of this model is 16mm.
This unit has a stroke length of 10mm.
The maximum operating pressure is 1 MPa.
It operates reliably within a temperature range of -10°C to 70°C.
It includes rubber cushioning to reduce impact and noise during operation.
The gross weight of this cylinder is 67g.
The guided rod design enhances lateral load resistance, providing stability in dynamic environments.
It features a through hole mounting type for flexible installation options.
The maximum piston speed is 500mm/s, supporting high-speed actuation tasks.
The body is made from aluminium alloy, which enhances durability and corrosion resistance.
This model belongs to the CQM series of pneumatic guided cylinders.
It operates as a double acting cylinder, allowing for controlled motion in both directions.
