SMC Pneumatic Guided Cylinder 16mm Bore, CQM Series, 30mm Stroke, Double Acting CDQMB16-30
Specifications
| Country of Origin | China |
|---|---|
| Brand | SMC |
| Body Material | Aluminium Alloy |
| Maximum Operating Pressure | 1 Mpa |
| Height | 29mm |
| Length | 61.5mm |
| Model | CDQMB16-30 |
| Gross Weight | 108g |
| Width | 29mm |
| Mount Type | Through Hole |
| Series | CQM |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -10°C |
| Stroke Length | 30mm |
| Bore Diameter | 16mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Cushioning Type | Rubber |
| Guide Type | Slide Bearing |
Key Features
- The double acting cylinder provides reliable bidirectional force for versatile applications.
- Constructed from hard anodized aluminium alloy for corrosion resistance and long service life.
- Features slide bearing guide type for smooth lateral load resistance and stability.
- Maximum operating pressure is 1 Mpa ensuring robust performance.
- Rubber cushioning type enhances impact absorption and cycle life.
- Operating temperature range from -10°C to 70°C supports diverse industrial environments.
- Through hole mount type allows flexible and secure installation.
- Suitable for industrial automation, pneumatic machinery, manufacturing and fluid power systems.
Product Description
SMC CDQMB16-30 Pneumatic Guided Cylinder is a precision-engineered component designed for reliable pneumatic automation tasks requiring guided motion and stable actuation. Featuring a 16mm bore diameter and a 30mm stroke length, this double acting cylinder efficiently converts pneumatic energy into linear motion.
Its hard anodized aluminium alloy body ensures exceptional durability and resistance to corrosion, ideal for industrial environments including manufacturing plants, HVAC systems, and fluid power applications. The integrated slide bearing guide type improves lateral load resistance by two to four times compared to standard cylinders, enhancing operational stability.
Operating at a maximum pressure of 1 Mpa with rubber cushioning absorbs impacts effectively, promoting extended lifecycle and minimizing wear. The through hole mounting type provides flexibility in secure installation across various equipment assemblies.
This cylinder operates efficiently across a temperature range from -10°C to 70°C, making it suitable for diverse ambient conditions. Its compact form factor with dimensions of 61.5mm length, 29mm width, and 29mm height, along with a lightweight design of 108 grams, supports easy integration in tight spaces.
The double acting mechanism allows bidirectional force application for versatile automation needs. Rubber cushioning ensures smooth operation and durability. Slide bearing guide enhances load capacity and precision. Hard anodized aluminium alloy body provides corrosion resistance.
Through hole mount design facilitates installation flexibility. Supports operating temperatures from -10°C up to 70°C. Compact size with a bore diameter of 16mm and 30mm stroke length. Lightweight at 108 grams for ease of handling and integration.
Manufactured in China under stringent quality controls, the CDQMB16-30 series is ideal for pneumatic cylinders and actuators in industrial tools and equipment. Explore EnvMart’s Pneumatic Guided Cylinders category for compatible products and extended automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 1 Mpa, ensuring robust performance for various applications.
This unit has dimensions of 61.5mm in length, 29mm in width, and 29mm in height.
The stroke length of the CDQMB16-30 is 30mm, allowing for effective linear motion.
This model features a bore diameter of 16mm, which is suitable for various pneumatic applications.
It uses rubber cushioning, which enhances impact absorption and extends the cycle life of the cylinder.
The operating temperature range is from -10°C to 70°C, making it suitable for diverse industrial environments.
This unit features a through hole mount type, allowing for flexible and secure installation.
The body is constructed from hard anodized aluminium alloy, providing corrosion resistance and durability.
It is a double acting cylinder, which allows for bidirectional force application.
This model utilizes a slide bearing guide type, which improves lateral load resistance and stability.
The gross weight of this unit is 108 grams, facilitating easy handling and integration.
This pneumatic guided cylinder is manufactured in China under stringent quality controls.
