SMC Pneumatic Guided Cylinder 40mm Bore MGP-Z Series Double Acting 50mm Stroke MGPM40TF-50Z

The SMC MGPM40TF-50Z Pneumatic Guided Cylinder is a compact guide cylinder designed specifically for automation and machinery requiring precise linear movement. It features a 40 mm bore diameter and a 50 mm stroke length with a robust double acting pneumatic operation.

Constructed with a stainless steel body, this guide cylinder offers excellent corrosion resistance, making it ideal for demanding industrial environments. The integrated slide bearing guide significantly reduces lateral play, improving positioning accuracy and increasing the lifespan of the guide system by lowering wear and maintenance frequency.

The cylinder supports a maximum operating pressure of 1 Mpa and a piston speed of up to 500 mm/s, allowing it to handle high-speed cycles necessary in manufacturing and process automation. Rubber cushioning at both ends absorbs shock and vibration, protecting the actuator and associated equipment.

Operating within temperatures ranging from -10°C to 60°C, it adapts well to various shop floor and enclosure conditions. The single rod with a G-thread piston rod standard simplifies installation and mechanical linkages.

This pneumatic guided cylinder is exceptionally suitable for applications such as pick-and-place assemblies, electronic component feeding, clamp actuation in electrical panel production, tool shifting in automated mechanical cells, and inspection stages requiring repeatable linear travel.

1 Mpa maximum operating pressure delivers strong actuation force. 500 mm/s maximum piston speed supports fast automation cycles. Slide bearing guide reduces wear and improves motion accuracy. Rubber bumpers on both ends mitigate shock and vibration.

Durable stainless steel construction resists corrosion. Single rod with G-thread enhances easy mounting. Wide temperature operating range from -10°C to 60°C. Compact width of 54 mm fits constrained spaces. Mass of 1.98 kg informs dynamic load and mounting bracket design.

Set contains the MGPM40TF-50Z pneumatic guided cylinder with a 50 mm stroke to suit short-travel linear tasks.

This guided cylinder is ideal for industrial, manufacturing, laboratory, automation, and mechanical system applications requiring precision, reliability, and compact pneumatic actuation.
