KEMET R75 Polypropylene Capacitor 47nF 5% Tolerance 2kV DC 700V AC Through Hole R75UN247050H3J

The KEMET R75UN247050H3J is a precision polypropylene film capacitor with capacitance of 47nF and a tolerance of 5%. It is rated for a maximum direct current voltage of 2kV DC and alternating current voltage of 700V AC, making it ideal for power electronics and industrial applications requiring high voltage tolerances.

This capacitor is designed for through-hole mounting with a lead pitch of 22.5mm and radial tinned leads of 0.8mm diameter and 25mm length. The encapsulation is a plastic, thermosetting resin material that is self-extinguishing and solvent-resistant, ensuring durability and reliability in harsh environments.

Its construction features metallized polypropylene dielectric layers, providing the capacitor with self-healing properties and high insulation resistance. The device meets international standards IEC 60286-2 and is RoHS compliant for environmental safety. Additionally, it meets the automotive industry standard AEC-Q200, ensuring reliability in automotive electronic circuits.

The capacitor operates efficiently in high-frequency and medium to high current circuits, including resonant circuits and silicon controlled rectifiers. With an equivalent series resistance of 16.9mΩ and a low dissipation factor of 0.04%, it offers minimal energy loss.

Operating temperature range spans from -55°C to 105°C, making it suitable for demanding industrial and electronic applications. Package dimensions include a length of 26.5mm, height of 18.5mm, and width of 10mm, facilitating compatibility with various PCB layouts.

This product is supplied in tape and reel packaging, supporting automated PCB assembly for high-volume manufacturing. The product is manufactured in China. KEMET capacitors are widely used in industrial, automotive, HVAC, manufacturing, and power supply applications where high voltage, reliability, and stability are critical.

Features a metallized polypropylene film dielectric for stable and reliable performance. Encapsulated in a plastic case that is self-extinguishing and solvent resistant. Rated for high frequency, medium to high current applications, and resonant circuits.

Lead free terminations with tinned radial leads and AEC-Q200 automotive standard compliance. Operating temperature range from -55°C to 105°C, suitable for demanding environments. Equivalent series resistance (ESR) of 16.9 mΩ ensuring low losses during operation.

Dimensions of 26.5mm length, 18.5mm height, and 10mm width with a 22.5mm lead pitch. Dissipation factor is 0.04%, which ensures low dielectric losses. Package supplied in tape and reel format for automated assembly processes.
