KEMET R75 Polypropylene Capacitor, 5 % Tolerance, 3.9 nF, 2 kV DC, 700V AC, Through Hole Mount R75UI139050H3J

Name: KEMET R75 Polypropylene Capacitor, 5 % Tolerance, 3.9 nF, 2 kV DC, 700V AC, Through Hole Mount R75UI139050H3J
Brand: KEMET
SKU: 109652
Price: 0.29 USD
Availability: InStock



Category Film Capacitors Brand KEMET Condition New

Specifications

Country of Origin	China
Brand	KEMET
Height	10mm
Length	18mm
Model	R75UI139050H3J
Packaging	Tape & Reel
Width	4mm
Mount Type	Through Hole
Series	R75
Maximum Operating Temperature	105°C
Tolerance	5 %
Capacitance	3.9nF
Minimum Operating Temperature	-55°C
Dissipation Factor	0.04%
Lead Length	25mm
Standards/Approvals	RoHS, IEC 60286-2
Package/Case	Plastic
Pin Count	2
Rated AC Voltage	700V ac
Rated DC Voltage	2kV dc
Lead Pitch	15mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200
Equivalent Series Resistance ESR	204mΩ

Key Features

Rated for 2 kV DC and 700V AC voltage compatibility.
Constructed with a plastic case and radial tinned wire leads.
Lead pitch is 15mm with 25mm lead length and 0.8mm diameter.
Operates within temperature range from -55°C to 105°C for reliable performance.
Features low dissipation factor of 0.04% ensuring energy efficiency.
Meets RoHS and IEC 60286-2 standards for compliance and safety.
Automotive grade quality with AEC-Q200 certification.
Equivalent Series Resistance (ESR) rated at 204 milliohms.

Product Description

KEMET R75UI139050H3J is a polypropylene film capacitor featuring a capacitance value of 3.9 nanofarads with a 5 percent tolerance. It is engineered for through hole mounting and rated for a maximum DC voltage of 2 kV and AC voltage up to 700V, suitable for various demanding electronic circuit applications.

This capacitor employs a metallized polypropylene film dielectric encapsulated in a solvent-resistant plastic case with thermosetting resin material, ensuring durability and high electrical insulation. The radial leads are composed of tinned wire with a lead pitch of 15mm, length of 25mm, and a diameter of 0.8mm for straightforward PCB mounting.

Its operating temperature range is from -55°C to 105°C, compliant with automotive standards per the AEC-Q200 specification, making it reliable in harsh environments. The capacitor exhibits a very low dissipation factor of 0.04%, which contributes to minimal energy loss and improved circuit efficiency.

Technical certification includes RoHS compliance and adherence to IEC 60286-2, underscoring its quality and safety standards. The ESR is rated at 204 milliohms, which impacts the capacitor’s internal losses and performance in AC circuits.

Rated AC voltage: 700V AC. Rated DC voltage: 2kV DC. Capacitance: 3.9 nF. Tolerance: 5 %. Lead pitch: 15mm. Operating temperature range: -55°C to 105°C. Package/Case: Plastic. Lead length: 25mm. Lead diameter: 0.8mm. Dimensions: 18mm length x 10mm height x 4mm width.

This polypropylene capacitor suits high frequency, resonant, and silicon controlled rectifier circuits, providing stable performance in demanding applications such as industrial electronics, automotive electronics, and power supplies. Its construction enables resistance to solvents and thermal stress, delivering longevity under tough operating conditions.
