Lovato Modulo Miniature Circuit Breaker 2-Pole 4A Type C 400V AC 80V DC 10kA Breaking Capacity P1MB
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Modulo |
| Brand | Lovato |
| Height | 86.5mm |
| Model | P1MB |
| Depth | 80mm |
| IP Rating | IP20 |
| Width | 36mm |
| Mount Type | DIN Rail |
| Current Rating | 4A |
| Series | P1MB |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 80V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Break Time | Instantaneous |
Key Features
- Features a Type C tripping curve for fast reaction to overloads.
- Operates at 400V AC and 80V DC rated voltages.
- Compact dimensions of 36mm width, 86.5mm height, and 80mm depth for DIN rail mounting.
- Has a mechanical lifespan of 20,000 cycles for long-term durability.
- Rated breaking capacity of 10 kA ensures effective short circuit interruption.
- Wide operating temperature range from -40°C to +70°C.
- Easy installation with screw terminal connections and 2 Nm maximum tightening torque.
- Complies with international standards IEC/EN/BS 60898-1, IEC/EN/BS 60947-2, CSA, UL, and others.
Product Description
Lovato P1MB Miniature Circuit Breaker, model P1MB2PC04, offers effective 2-pole electrical protection with a 4A current rating. Designed for use at 400 volts AC and 80 volts DC, this MCB provides high reliability and safety in multiple electrical systems.
This Type C circuit breaker protects against overloads and short circuits with a breaking capacity of 10 kA, preventing damage to wiring and equipment. The thermal magnetic tripping mechanism enables instantaneous response during fault conditions, enhancing system safety.
Constructed to mount on a standard DIN rail, it features a compact size of 36 mm width, 86.5 mm height, and 80 mm depth, making it suitable for a variety of panel configurations. The device supports quick and secure installation via screw terminals with a maximum tightening torque of 2 Nm.
Its robust design supports operation in harsh environments with temperatures ranging from -40°C to +70°C, ensuring durability and consistent performance. The mechanical endurance is rated up to 20,000 cycles, signifying long service life.
This MCB meets global safety standards including IEC/EN/BS 60898-1, IEC/EN/BS 60947-2, CSA, cURus, EAC, and UL 1077, reinforcing quality and compliance for electrical installations.
Type C tripping curve ensures appropriate response to inrush currents and moderate overloads. High breaking capacity of 10 kA prevents damage from short circuits. Thermal magnetic tripping mechanism provides reliable protection.
Compact DIN rail mount design suits varied installation spaces. Wide operational temperature range accommodates diverse environments. Secure screw terminals with 2 Nm torque for stable connections. Mechanical life of 20,000 cycles for extended durability.
Compliant with multiple international safety standards. Ideal for residential, commercial, and industrial electrical systems. Explore more Miniature Circuit Breakers and electrical protection devices in the Electronics & Electricals category at EnvMart for professional and safe electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Lovato Modulo Miniature Circuit Breaker has a breaking capacity of 10 kA, which ensures effective interruption of short circuits.
This circuit breaker operates at a rated voltage of 400V AC and 80V DC, making it suitable for various electrical systems.
It features a Type C tripping characteristic, which provides a fast reaction to overloads, particularly suitable for inrush currents.
This model has compact dimensions of 36 mm in width, 86.5 mm in height, and 80 mm in depth, making it suitable for DIN rail mounting.
It is designed for DIN rail mounting, allowing for easy installation in various panel configurations.
The mechanical lifespan of this model is rated for up to 20,000 cycles, indicating its durability for long-term use.
This unit operates effectively within a wide temperature range of -40°C to +70°C, suitable for harsh environments.
It employs a thermal magnetic tripping mechanism, which provides instantaneous response during fault conditions.
The Lovato Modulo Miniature Circuit Breaker features screw terminals for secure and stable connections.
This model complies with international standards including IEC/EN/BS 60898-1, IEC/EN/BS 60947-2, CSA, and UL 1077, ensuring safety and quality.
The high breaking capacity of 10 kA helps prevent damage to wiring and equipment by effectively interrupting short circuits.
It is suitable for residential, commercial, and industrial electrical systems, providing reliable protection across various applications.
