Amphenol Limited MIL Spec Circular Connector 19 Contacts Copper Alloy Straight 700V 7.5A Cable Bayonet Mount 62GB-56TG14-19PN
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 700V |
| Brand | Amphenol Limited |
| Orientation | Straight |
| Current | 7.5A |
| Model | 62GB-56TG14-19PN |
| Temperature Operating Range | -55°C to 125°C |
| Mount Type | Cable |
| Contact Material | Copper Alloy |
| Series | 62 GB |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 19 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 14 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Wire gauges and current carrying capabilities | Upto 45A and size 24 to 8 AWG wires |
Key Features
- Offers a high current rating of 7.5A and voltage support up to 700V.
- Features gold plated contacts for superior conductivity and corrosion resistance.
- Operates reliably within a wide temperature range from -55°C to 125°C.
- Utilizes a bayonet mating type ensuring secure and quick connection.
- Designed with a straight orientation and cable mount for flexible installation.
- Meets MIL-DTL-26482 military standard for rugged applications.
- Includes crimp termination type for secure wire attachment.
- Constructed with a copper alloy contact material for strength and durability.
Product Description
Amphenol Limited 62GB-56TG14-19PN MIL Spec Circular Connector is a high-performance connector designed for demanding industrial and military applications. It features a copper alloy body with 19 female contacts and gold plating to ensure excellent electrical performance and corrosion resistance.
Operating voltage reaches up to 700V with a current rating of 7.5A, suited for robust cable connections in electronics and power systems. The connector supports a wide temperature range from -55°C to 125°C, making it suitable for harsh environments.
Its straight cable orientation and bayonet mating type allow for easy and secure connection in installations requiring reliability and durability. The connector complies with MIL-DTL-26482 military standards, ensuring ruggedness and dependability under extreme conditions.
Termination is accomplished via crimping, providing a reliable electrical and mechanical connection. The connector's copper alloy contacts provide strength while maintaining conductivity, reinforced by gold plating for consistent performance. This product is manufactured in the United Kingdom, highlighting quality and precision in production.
High current rating of 7.5A and 700V voltage capability. Gold plated female contacts enhance signal integrity. Wide operating temperature range of -55°C to 125°C. Bayonet mating type for secure and rapid connections. Cable mount type with straight orientation for installation flexibility.
Meets MIL-DTL-26482 military standard for durability and reliability. Crimp termination ensures dependable wire attachment. Copper alloy contact material provides mechanical and electrical robustness. Country of origin: United Kingdom.
This MIL Spec circular connector from Amphenol Limited is ideal for use in industrial, military, aerospace, and other high-reliability applications where signal integrity and mechanical endurance are critical. It is suitable for use in electronic components, power connectors, and cable assembly systems requiring a durable and approved connector solution.
Explore more high-quality circular connectors and related accessories in our Electronics Components category at EnvMart.
Explore more products in our Mil Spec Circular Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 700V, making it suitable for robust cable connections in electronics and power systems.
The connector supports a current rating of 7.5A, allowing it to handle significant electrical loads.
This model operates reliably within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
It features 19 female contacts, designed to provide reliable electrical connections.
The connector utilizes a crimp termination type, ensuring a secure and reliable wire attachment.
It employs a bayonet mating type, which allows for secure and quick connections during installation.
The contacts are made from copper alloy and are gold plated to enhance conductivity and corrosion resistance.
It has a straight orientation and is designed for cable mounting, providing flexibility during installation.
This model meets the MIL-DTL-26482 military standard, ensuring it is rugged and reliable for demanding applications.
The shell size of this connector is 14, which is standard for this type of MIL Spec circular connector.
It supports wire gauges from size 24 to 8 AWG, accommodating a range of current carrying capabilities up to 45A.
This connector is manufactured in the United Kingdom, highlighting quality and precision in production.
