Vishay Single Layer Ceramic Capacitor 470pF 1kV DC ±10% S3N Dielectric Radial Through Hole Disc 125°C Max F471K25S3NN63J5R
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1kV dc |
| Diameter | 6.5mm |
| Brand | Vishay |
| Height | 40mm |
| Model | F471K25S3NN63J5R |
| Width | 18mm |
| Mount Type | Through Hole |
| Series | F |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 470pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Radial |
| Dissipation Factor | 0.2% |
| Standards/Approvals | EC, RoHS |
| Package/Case | Disc |
| Pin Count | 2 |
| Dielectric | S3N |
| Suppression Class | Class I |
Key Features
- Capacitance of 470 pF provides precise filtering and tuning performance.
- Rated for 1kV DC voltage ensuring high voltage tolerance.
- Dielectric type S3N enables stable operation at high frequencies.
- Operating temperature range from -30°C to +125°C suits various industrial environments.
- Radial through-hole mounting with kinked leads ensures secure installation in PCB designs.
- Disc package with 2-pin terminals and silver-plated ceramic discs enhances reliability.
- Class I suppression class offers low losses and high stability.
- Flame-resistant epoxy resin encapsulation complies with UL 94 V-0 standards.
Product Description
Vishay F471K25S3NN63J5R is a single layer ceramic capacitor designed for demanding electronic applications requiring low losses and high capacitance stability. It features a capacitance of 470pF with ±10% tolerance and is rated for 1 kV DC voltage, offering reliable performance in high voltage circuits.
The capacitor uses an S3N dielectric which provides excellent behavior in switch-mode power supply (SMPS), high frequency ballast, and snubber circuit applications. The capacitor body consists of a ceramic disc coated on both sides with silver plating. Connection leads are made of tinned copper with diameters 0.6 mm or 0.8 mm, kinked for ease of mounting and spacing of 5 mm, 7.5 mm, or 10 mm.
The epoxy resin encapsulation is flame retardant, complying with UL 94 V-0 specifications, enhancing safety in industrial uses. Operating temperature extends from -30°C to +125°C, suitable for diverse environmental conditions encountered in industrial, commercial, and laboratory electronics.
This radial through-hole component features 2 pins and a disc form factor with diameter of 6.5 mm, height 40 mm, and width 18 mm. It aligns with IEC 60384-9 and RoHS regulations supporting electronic manufacturing standards.
470pF capacitance with ±10% tolerance ensures precision in tuning applications. 1 kV DC voltage rating supports high voltage circuit designs. S3N dielectric for low loss and high-frequency operation. Flame-retardant epoxy resin encapsulation enhances safety.
Radial through-hole mounting with kinked leads for robust PCB installation. Class I suppression class for high stability and reliability. Silver-plated ceramic discs for enhanced conductivity and protection. Operational temperature range of -30°C to +125°C accommodates harsh environments.
Complies with IEC 60384-9 and RoHS standards for quality and environmental compliance.
This capacitor is perfectly suited for industrial electronics, electronic circuit manufacturing, power supplies, and high-frequency control systems. Vishay's FT series components offer proven reliability and performance in critical applications.
Explore more capacitors and electronic components on EnvMart for your design and manufacturing needs.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitor has a capacitance value of 470 pF with a tolerance of ±10%.
It is rated for a maximum voltage of 1 kV DC, making it suitable for high voltage applications.
The operating temperature range extends from -30°C to +125°C, accommodating various industrial environments.
This model utilizes an S3N dielectric, which provides stability at high frequencies and low losses.
It features a radial through-hole mounting type, which ensures secure installation in PCB designs.
The capacitor has a diameter of 6.5 mm, a height of 40 mm, and a width of 18 mm.
This model has 2 pins, which are kinked for ease of mounting.
It complies with EC and RoHS standards, ensuring quality and environmental compliance.
It is classified as Class I suppression, which offers high stability and reliability.
The capacitor is encapsulated in flame-retardant epoxy resin, complying with UL 94 V-0 standards.
This capacitor is suitable for industrial electronics, electronic circuit manufacturing, power supplies, and high-frequency control systems.
The dissipation factor for this model is 0.2%, indicating low energy loss during operation.
