BEL POWER SOLUTIONS INC Q Series DC/DC Converter 5.1V 20mA 36V Input 14.4V Input 102W Max Temp 71°C Model BQ1001-9R
Specifications
| Country of Origin | India |
|---|---|
| Brand | BEL POWER SOLUTIONS INC |
| Efficiency | 86% |
| Length | 172mm |
| Model | BQ1001-9R |
| Depth | 20mm |
| Gross Weight | 500g |
| Series | Q |
| Maximum Operating Temperature | 71°C |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 5 |
| Maximum Output Power | 102W |
| Maximum Input Voltage | 36V |
| Standards/Approvals | CSA, UL, IEC, EN |
| Minimum Input Voltage | 14.4V |
| Output Voltage 1 | 5.1V |
| Output Current 1 | 20mA |
| Isolation Voltage | 4.2kV |
Key Features
- This converter supports 14.4V minimum and 36V maximum input voltages to provide flexible power management.
- It delivers a maximum output power of 102W ensuring reliable performance under heavy loads.
- The device features 5 isolated outputs with 4.2kV isolation voltage for enhanced safety.
- Designed for harsh environments with operating temperatures ranging from -40°C to 71°C.
- Encased in a black-coated aluminium housing that acts as a heat sink and RFI shield.
- Compliant with industry standards including CSA, UL, IEC, and EN for quality assurance.
- Compact design fits 19" DIN rack systems with chassis mount option using four M3 screws.
- Offers high efficiency of 86% reducing energy waste and thermal load.
Product Description
BEL POWER SOLUTIONS INC BQ1001-9R is a high-performance Q Series DC/DC Converter delivering 5.1V output at 20mA output current, compatible with input voltages from 14.4V to 36V. Rated for maximum output power of 102W, it operates efficiently at 86% efficiency, making it suitable for demanding industrial and electronic use cases.
This converter is engineered for rugged environments and complies with CSA, UL, IEC, and EN standards, including European railway norms EN 50155 and EN 50121-3-2. Its robust black-coated aluminium enclosure provides heat dissipation and electromagnetic interference shielding, ensuring reliable operation in harsh conditions.
The device features five isolated outputs with an isolation voltage of 4.2kV, supporting flexible wiring configurations such as series or parallel connection. It offers comprehensive protective functions including low inrush current, overtemperature protection, and voltage lockout safeguards.
Designed primarily for 19" DIN rack mounting but also suitable for chassis mounting via four M3 screws, this converter occupies 3U/4TE space. It includes conformal coating to protect against humidity and dust ingress. The operating temperature range spans from -40°C minimum to 71°C maximum, enabling use in extreme industrial environments.
Applications include industrial power supplies, railway electronics, telecommunications, manufacturing systems, and other commercial sectors requiring reliable DC/DC voltage conversion with high isolation and efficiency.
This converter ensures excellent surge and transient protection for sensitive circuitry. Hot plug capability and current sharing support redundant application designs. Compact dimensions of 172mm length, 20mm depth, and 111mm height facilitate installation in constrained spaces.
Low ripple and radio frequency interference (RFI) noise levels enhance compatibility with sensitive electronic systems. Package includes this single DC/DC converter unit with all required mounting accessories. Explore EnvMart's complete collection of advanced DC/DC Converters from BEL POWER SOLUTIONS INC for dependable industrial power regulation.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 102W.
It supports a minimum input voltage of 14.4V and a maximum input voltage of 36V.
This unit features five isolated outputs.
The efficiency of this model is rated at 86%.
It operates within a temperature range of -40°C to 71°C.
The isolation voltage for this converter is 4.2kV.
The dimensions are 172mm in length, 20mm in depth, and 111mm in height.
It is designed for 19" DIN rack mounting and can also be chassis mounted using four M3 screws.
It complies with CSA, UL, IEC, and EN standards, including European railway norms EN 50155 and EN 50121-3-2.
It is suitable for industrial power supplies, railway electronics, telecommunications, and manufacturing systems.
It includes low inrush current, overtemperature protection, and voltage lockout safeguards.
The gross weight of this model is 500g.
