Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 5 Contact, 2.54 mm Pitch, 1 Row 811-S1-005-10-017101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 811-S1-005-10-017101 |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 811 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Enables low resistance, stable electrical connections through spring-loaded contacts.
- Constructed with brass contacts plated in gold for reliable conductivity.
- Fibreglass reinforced polyethylene terephthalate housing ensures durability.
- Operates efficiently across a temperature range from -55°C to 125°C.
- Supports a current rating of 3.5A and voltage rating of 150V.
- Male contact gender with solder termination type for secure PCB attachment.
- Designed for straight orientation and 1 row configuration.
- Ideal for electronics manufacturing and assembly requiring reliable multipoint connections.
Product Description
Preci-Dip 811-S1-005-10-017101 Spring Loaded Connector features 5 spring-loaded contacts arranged in a single row with a 2.54 mm pitch, designed for through-hole PCB mounting and shrouded protection.
The connector’s brass contacts are gold plated, providing excellent electrical conductivity and corrosion resistance. Its housing is constructed from fibreglass reinforced polyethylene terephthalate, offering mechanical strength and thermal stability suitable for industrial electronics applications.
Operating temperature ranges from -55°C to 125°C, allowing use in diverse environments. The connector supports up to 3.5A current and 150V voltage, making it suitable for demanding circuits requiring low resistance multi-point connections.
Spring-loaded contacts maintain constant electrical contact even in vibration or movement scenarios, enhancing reliability over conventional connectors. The male contact gender with solder termination ensures robust mechanical and electrical mounting to PCBs.
This high-precision connector is manufactured in Switzerland, adhering to stringent industrial standards although it does not carry specific certifications. It is ideal for industrial, manufacturing, and electronic assembly applications requiring compact, reliable PCB connectors.
Low resistance spring-loaded contact design guarantees stable performance under vibration. Reliable gold-plated brass contacts enhance conductivity and durability. Durable fibreglass reinforced housing withstands mechanical and thermal stresses.
Temperature rating from -55°C to 125°C suitable for harsh environments. Compact 2.54 mm pitch spacing and single-row layout optimizes PCB space usage. Shrouded design protects contacts and prevents damage during handling.
Supports up to 3.5A current and 150V voltage for diverse electronic applications. Through hole mounting with solder termination enables strong PCB connection. Manufactured in Switzerland ensuring quality and precision without specific approvals.
Explore the Preci-Dip range of PCB Connectors for robust electronics design and manufacturing solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector supports a maximum current rating of 3.5A.
It has a voltage rating of 150V.
The pitch size is 2.54 mm.
The contacts are made of brass and are gold plated, while the housing is constructed from fibreglass reinforced polyethylene terephthalate.
It operates efficiently across a temperature range from -55°C to 125°C.
This model features 5 contacts.
It uses a solder termination type for secure PCB attachment.
The connector is designed for straight orientation.
Yes, it is ideal for industrial, manufacturing, and electronic assembly applications requiring reliable multipoint connections.
The contact gender is male.
Yes, it features a shrouded design that protects the contacts and prevents damage during handling.
It is manufactured in Switzerland.
