SMC Pneumatic Guided Cylinder 6mm Bore, MXS Series, 30 mm Stroke, Double Acting, Through Hole Mount, Aluminium Alloy MXS6-30

SMC MXS6-30 Pneumatic Guided Cylinder features a 6 mm bore diameter and 30 mm stroke in the MXS air slide table series, offering precision double acting pneumatic actuation with a through hole mount and aluminium alloy construction.

This cylinder is engineered for applications requiring accurate linear motion, combining an integrated cross roller bearing guide with compact air cylinders for force generation. Its slide bearing guide type provides stable and precise movement, while rubber cushioning reduces impact for smooth operation.

The MXS6-30 supports a maximum operating pressure of 0.7 MPa and piston speeds up to 500 mm/s, optimized for efficient and reliable pneumatic control. It operates effectively within the temperature range of -10°C to 60°C, making it adaptable to various industrial and manufacturing environments.

Additional features include an M3 piston rod thread size, compact dimensions (68 mm length, 32 mm width, 20 mm height), and aluminium alloy body for corrosion resistance and reduced weight. Its double acting design enables controlled piston movement in both extension and retraction strokes, suitable for robotic, assembly automation, and fluid power systems.

This pneumatic guided cylinder features a 6 mm bore diameter for compact assembly. The MXS series design incorporates a double acting mechanism for controlled force in both directions. Mounting is through hole type, ideal for secure installation in various applications.

Constructed with a durable aluminium alloy body for lightweight and corrosion resistance. Cushioning is provided by rubber for smooth operation and reduced impact. The cylinder supports a maximum operating pressure of 0.7 MPa for reliable pneumatic power.

Operating temperature ranges from -10°C to 60°C, suitable for diverse industrial environments. It incorporates slide bearing guide type with cross roller bearing for precise movement and stability. Maximum piston speed is rated at 500 mm/s for efficient actuation speed.

The piston rod thread size is M3, compatible with standard pneumatic fittings. The compact dimensions of length 68 mm, width 32 mm, and height 20 mm aid versatile mounting options. The stroke length is 30 mm, providing a measured linear travel suitable for precise positioning.

This product is widely used in industrial tools and equipment for hydraulic and pneumatic applications, including manufacturing, automation, laboratory equipment, and fluid power control. Its precise engineering makes it an excellent solution for tasks demanding stable and repeatable motion control.
