Omron Pin Plunger Subminiature Micro Switch Solder Terminal 100mA 250V AC 30V DC SPDT IP40 SSG-01H
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Omron |
| Model | SSG-01H |
| IP Rating | IP40 |
| Width | 6.4mm |
| Series | SSG |
| Maximum Operating Temperature | 125°C |
| Contact Configuration | SPDT |
| Actuator Type | Pin Plunger |
| Minimum Operating Temperature | -25°C |
| Terminal type | Solder |
| Standards/Approvals | RoHS |
| Contact DC Voltage | 30V dc |
| Switch Contact Current | 100mA |
| Operating Force | 1.5N |
| Mechanical Life | 10000000Operations |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Subminiature |
| Dimensions (body) | H9.9mm, W19.8mm, D6.4mm |
Key Features
- Subminiature microswitch design with V4 style housing for compact applications.
- Pin plunger actuator for precise and sensitive operation.
- Solder terminal type for secure and reliable electrical connections.
- Contact configuration is Single Pole Double Throw (SPDT) for versatile switching.
- Protection rating of IP40 guarding against solid particle ingress.
- Operating force of 1.5 Newtons ensures tactile feedback and reliability.
- Wide operating temperature range from -25°C to 125°C for industrial environments.
- Mechanical life rated for up to 10 million operations, ensuring long-term use.
Product Description
Omron SSG-01H is a pin plunger subminiature micro switch with solder terminals designed for precision switching applications in industrial and electronic environments. Rated for 100mA current at 250 V AC and 30 V DC voltages, it features a compact V4 style housing measuring approximately 9.9 mm height, 19.8 mm width, and 6.4 mm depth.
This subminiature microswitch utilizes a pin plunger actuator that provides sensitive and reliable tactile switching with an operating force of 1.5 N. Its SPDT contact configuration enables it to perform versatile changeover switching roles in control circuits.
With an IP40 ingress protection rating, the switch is resistant to solid objects larger than 1 mm, making it suitable for indoor and controlled industrial applications. It is capable of operating reliably over a broad temperature range from -25°C to 125°C, accommodating demanding environmental conditions.
Designed for longevity, the switch mechanical life expectancy is about 10 million cycles, assuring consistent performance in automated systems, instrumentation, and safety devices. The solder terminal type ensures secure wire connections on PCBs or wiring harnesses, improving installation reliability.
Subminiature V4 style housing for compact installations. Pin plunger actuator provides accurate actuation. Rated for 100mA contacts, 250V AC and 30V DC voltages. SPDT contact configuration for versatile switching. IP40 rated for protection against dust ingress.
Operating force at 1.5N offers distinct tactile response. Wide temperature tolerance from -25°C to 125°C. Mechanical life of 10 million operations supports durability. RoHS compliant and manufactured in Japan.
The Omron SSG-01H micro switch is well suited for use in industrial automation, electronic control systems, HVAC equipment, and instrumentation applications that require precise and reliable switching operation within compact spaces. This product ensures consistent performance and longevity under varied environmental conditions.
Explore the broad range of Micro Switches and industrial components at EnvMart for all your precision switching needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for the Omron SSG-01H micro switch is 125°C.
This model features a Single Pole Double Throw (SPDT) contact configuration, allowing for versatile switching applications.
The operating force of the SSG-01H is 1.5 Newtons, providing tactile feedback during operation.
The dimensions of the SSG-01H are approximately 9.9 mm in height, 19.8 mm in width, and 6.4 mm in depth.
The SSG-01H has an IP40 ingress protection rating, guarding against solid particles larger than 1 mm.
The mechanical life expectancy of the SSG-01H is rated for up to 10 million operations, ensuring long-term use.
This micro switch utilizes a pin plunger actuator, which allows for precise and sensitive operation.
The SSG-01H is rated for a contact current of 100mA, with a voltage of 250V AC and 30V DC.
This model features solder terminals, which provide secure and reliable electrical connections.
The minimum operating temperature for the SSG-01H is -25°C, making it suitable for various industrial environments.
Yes, the SSG-01H is RoHS compliant, meeting environmental standards for hazardous substances.
The Omron SSG-01H micro switch is manufactured in Japan.
