ERNI SMC Series Straight Surface PCB Socket 12-Contact 2 Row 1.27 mm Pitch Solder 154717 / 154717-E

ERNI 154717 / 154717-E SMC Series Straight Surface PCB Socket is a high-density, 12-contact, 2-row board-to-board connector with a 1.27 mm pitch and solder termination. This connector features a robust dual beam contact design that guarantees low resistance and outstanding contact reliability, ensuring high electrical performance for demanding industrial and electronic applications.

The housing is manufactured from liquid crystal polymer, lending excellent mechanical strength and thermal stability. The connector operates over a broad temperature range of -55°C to 125°C, making it suitable for harsh industrial environments including manufacturing, telecommunications, and electronic assembly.

The soldering brackets provide secure retention on the PCB and absorb mechanical stresses to withstand shock and vibrations, which is critical for industrial and commercial equipment reliability. The dual beam contacts and gold plating ensure durability and superior conductivity over extensive mating cycles, up to 500 mating operations.

The SMC series connectors support high-speed data signals at rates of up to 3 Gbit/s, making them ideal for modern electronics requiring fast and reliable communication lines. Their polarization features and locating pegs ensure precise mating and alignment to prevent mis-insertion during automated assembly processes.

This straight surface mount PCB Socket includes a stacking height of 9.05 mm with a 1.5 mm row pitch, offering design flexibility and compact PCB footprint. It is engineered specifically for fully automated board assembly environments to enhance production throughput. The product is manufactured in Germany to high-quality standards, ensuring consistent performance.

Ultra reliable dual beam contact design for maximum contact reliability and low resistance. Compact high-density connector optimizing PCB space usage. High-speed signal integrity supporting data rates up to 3 Gbit/s. Wide operating temperature range from -55°C to 125°C for versatile application.

Polarization and locating pegs for accurate and secure PCB placement. Soldering brackets for robust mechanical retention on PCB and vibration resistance. Durable liquid crystal polymer housing ensuring mechanical strength and thermal performance.

Suitable for fully automated board assembly ensuring manufacturing efficiency. Gold plated copper alloy contacts enhance electrical performance and durability. Stacking height of 9.05 mm and 1.5 mm row pitch for flexible mounting options.
