ERNI HDE-20 Series Polycarbonate Angled D-Sub Backshell 25 Way Strain Relief 1-747947-5

Free Delivery in India | Lowest Global Shipping Charges

ERNI HDE-20 Series Polycarbonate Angled D-Sub Backshell 25 Way Strain Relief 1-747947-5

Name: ERNI HDE-20 Series Polycarbonate Angled D-Sub Backshell 25 Way Strain Relief 1-747947-5
Brand: ERNI
SKU: 422937
Price: 20.22 USD
Availability: InStock



Category D-Sub Backshell Brand ERNI Condition New

Specifications

Country of Origin	India
Brand	ERNI
Colour	German Silver
Orientation	Angled
Housing Material	Polycarbonate
Series	HDE-20
Number of Contacts	25
Connector Type D	D-Sub Backshell
D-Sub Shell Size	B
Housing Plating	Die Cast Zinc
ERNI 63 Series Polycarbonate Angled D-Sub Backshell, 25 Way Strain ReliefBrand	ERNI

Key Features

Constructed with durable polycarbonate housing for longevity.
Angled design facilitates cable routing in tight spaces.
25 way strain relief ensures secure wire retention.
Housing plating is die cast zinc for enhanced EMI/RFI shielding.
Includes German silver color for corrosion resistance.
Compatible with IDC D-Sub connectors supporting 30 - 26 AWG solid wire size.
Supplied with M3 or 4-40 UNC jackscrews for assembly.
Maximum height to cable entry is 40 mm for cable management.

Product Description

ERNI 1-747947-5 HDE-20 Series Polycarbonate Angled D-Sub Backshell is engineered to provide exceptional strain relief for 25-position D-Sub connectors. Featuring a robust polycarbonate housing and die cast zinc plating, this backshell offers superior mechanical protection and EMI/RFI shielding essential for industrial, electronic, and telecommunications applications.

The angled design aids in efficient cable routing when space is constrained, while the German silver color enhances corrosion resistance. The backshell supports shielded cable-to-cable connections utilizing 30 to 26 AWG solid wire sizes, making it ideal for high-performance IDC D-Sub connectors.

Assembly is facilitated by the inclusion of M3 or 4-40 UNC jackscrews, ensuring secure connector mounting. The maximum height of 40 mm to cable entry accommodates extended insulator lengths typical in AMPLIMITE HDEShielded series connectors, providing reliable protection against EMI and mechanical strain.

This backshell is suitable for applications spanning industrial electronics, communications equipment, and power connectors where durability and shield integrity are critical. Its compatibility with ITT Cannon D*JK filter connectors further broadens its usage scope.

The protective backshell design not only enhances connector longevity but also safeguards sensitive electronic signals from electromagnetic interference, contributing to system reliability in harsh environments.

Constructed with durable polycarbonate for long-lasting use. Designed with die cast zinc plating for EMI/RFI shielding. Angled housing optimizes cable management and routing. Includes strain relief for 25-way cable retention.

Compatible with 30 - 26 AWG solid wire size connectors. Offers maximum height of 40 mm to cable entry. Accommodates extended insulator lengths of HDEShielded connectors. Includes M3 and 4-40 UNC jackscrews for secure assembly.
