Schneider Electric ComPact NSXm Molded Case Circuit Breaker 4-Pole 25A 16kA Breaking Capacity DIN Rail LV426121
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426121 |
| Depth | 137mm |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 25A |
| Series | NSXm |
| Terminal type | Screw |
| Breaking Capacity | 16kA |
| Number of Poles | 4 |
| Standards/Approvals | CCC, CE, EAC, EN, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Mount Hole Size | 4.5 mm |
Key Features
- This compact NSXm series circuit breaker supports current ratings from 16 to 160 A.
- Equipped with a thermal magnetic tripping mechanism for reliable overload and short circuit protection.
- Mounting is suited for standard DIN rail installations with 4.5 mm mount hole size.
- Terminal type is screw, ensuring secure electrical connections.
- Rated AC voltage is 690 V AC, suitable for industrial applications.
- Tripping characteristic is Type D, designed for motor and inductive loads.
- Reset actuator is a toggle switch for easy manual reset after tripping.
Product Description
Schneider Electric LV426121 ComPact NSXm Molded Case Circuit Breaker is a premium electrical protection device designed for industrial and commercial applications. This 4-pole MCCB provides dependable protection against overloads and short circuits, supporting a current rating of 25A and a breaking capacity of 16 kA, suitable for heavy-duty electrical circuits.
The compact design makes it ideal for DIN rail mounting in control panels, minimizing space while maximizing protection. The breaker features a thermal magnetic trip mechanism with Type D tripping characteristics, specifically designed to manage motor start-ups and inductive loads efficiently.
Constructed with durable materials and compliant with international standards including CCC, CE, EAC, EN, IEC, and RoHS, it ensures safety and reliability. The screw-type terminals provide robust and secure electrical connections, essential in critical electrical systems.
Physical dimensions are 137 mm in height, 80 mm in width, and 137 mm in depth, offering a compact solution without compromising performance. The toggle switch reset actuator allows for straightforward manual resetting following any tripping event.
This molded case circuit breaker belongs to Schneider Electric's ComPact series, NSXm range, providing flexibility to accommodate currents from 16 to 160 A with options for integrated earth leakage protection. It is extensively used in industrial, manufacturing, electrical distribution, and automation environments.
Compact NSXm series molded case Circuit Breaker for robust electrical protection. 4-pole configuration supporting 25A current rating. High breaking capacity of 16 kA for effective fault clearance. Thermal magnetic trip mechanism with Type D tripping characteristics.
DIN rail mounting for convenient installation. Compliance with multiple international safety standards. Screw terminal type for secure connections. Toggle switch reset actuator for ease of use. Compact dimensions suitable for industrial control panels.
Designed for industrial, manufacturing, and automation applications. Explore the Schneider Electric range on EnvMart for high-quality electrical protection solutions tailored to diverse industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 25A.
It has a breaking capacity of 16 kA, suitable for effective fault clearance.
The rated AC voltage is 690V AC, making it suitable for industrial applications.
It features a thermal magnetic tripping mechanism for reliable overload and short circuit protection.
The physical dimensions are 137 mm in height, 80 mm in width, and 137 mm in depth.
It is designed for DIN rail mounting, with a mount hole size of 4.5 mm.
This unit is equipped with screw-type terminals for secure electrical connections.
It has Type D tripping characteristics, which are designed for motor and inductive loads.
It complies with multiple international standards including CCC, CE, EAC, EN, IEC, and RoHS.
The reset actuator is a toggle switch, allowing for easy manual resetting after tripping.
It belongs to the NSXm series of Schneider Electric's ComPact range.
It is extensively used in industrial, manufacturing, electrical distribution, and automation environments.
