Panasonic WE-GF 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 μH ±10% 60 mA Idc Q30 744764147
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 2.2mm |
| Length | 3.2mm |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | WE-GF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Package/Case | 1210 |
| Maximum DC Current | 60mA |
| Pin Count | 2 |
| Maximum DC Resistance | 7Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 15MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- Compact 1210 package size suitable for surface mounting.
- Ferrite core material for stable magnetic properties.
- Shielded construction reduces electromagnetic interference.
- Operating temperature range from -40°C to 105°C.
- Low DC resistance of 7 ohms ensures efficient performance.
- Minimum quality factor of 30 optimizes resonance characteristics.
- Moulded design enhances mechanical durability.
- Maximum self-resonant frequency of 15 MHz supports high-frequency applications.
Product Description
Wurth Elektronik 744764147 WE-GF series shielded wirewound surface mount inductor features a ferrite core with an inductance of 47 μH and ±10% tolerance. Rated for a maximum DC current of 60 mA and offering a quality factor (Q) of 30, this component supports operating temperatures from -40°C to 105°C, making it ideal for robust industrial and electronic applications.
The 1210 package size with dimensions 3.2 mm length, 2.2 mm height, and 2.5 mm depth allows efficient surface mounting on printed circuit boards. Its shielded wirewound construction reduces electromagnetic interference, delivering reliable magnetic performance in high-frequency circuits up to a maximum self-resonant frequency of 15 MHz. The low DC resistance of 7 ohms ensures minimal power losses during operation.
This inductor is moulded to enhance durability and has a two-pin termination style suitable for automated reel-based assembly processes. It is widely used in electronic circuits such as HF amplifiers, oscillators, transponders, LC filter circuits, and adapter networks. Designing with this component supports industrial, telecommunications, laboratory instrumentation, and high-frequency electronic circuit applications.
Compact 1210 surface mount package. Ferrite core for stable inductance. Shielded wirewound construction. 47 μH inductance with ±10% tolerance. 60 mA maximum DC current rating. Operating temperature range -40°C to 105°C. Low 7 Ω DC resistance.
High-quality factor (Q) of 30 minimum. Moulded for mechanical strength. High frequency operation up to 15 MHz.
Choose Wurth Elektronik WE-GF series inductors for reliable Surface Mount Inductors compatible with high-frequency applications and demanding industrial environments. Explore more electronic components for your design needs with EnvMart's comprehensive catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 47 μH with a tolerance of ±10%.
This model has a maximum DC current rating of 60 mA.
The operating temperature range for this inductor is from -40°C to 105°C.
The maximum self-resonant frequency of this inductor is 15 MHz, making it suitable for high-frequency applications.
The dimensions of the 1210 package are 3.2 mm in length, 2.2 mm in height, and 2.5 mm in depth.
This inductor has a low DC resistance of 7 ohms, which helps ensure efficient performance.
The core material used in this inductor is ferrite, which provides stable magnetic properties.
The minimum quality factor (Q) of this inductor is 30, optimizing resonance characteristics.
This inductor is packaged in tape and reel format, suitable for automated assembly processes.
This inductor features a surface mount termination style with a two-pin configuration.
This inductor is widely used in electronic circuits such as HF amplifiers, oscillators, and LC filter circuits.
This inductor is constructed using a wirewound method, which enhances its performance in various applications.
