RS PRO PCB Terminal Block 3-Contact 5.08 mm Pitch Through Hole 1 Row CTB0509
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 300V |
| Brand | RS PRO |
| Colour | Green |
| Orientation | Vertical |
| Current | 10A |
| Length | 15.14mm |
| Model | CTB0509 |
| Depth | 10.1mm |
| Width | 8.3mm |
| Mount Type | Through Hole |
| Housing Material | Polyamide 66 |
| Series | CTB0509 |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Number of Contacts | 3 |
| Minimum Wire Size mm² | 0.13mm² |
| Maximum Wire Size mm² | 1.31mm² |
| Minimum Wire Size AWG | 26AWG |
| Maximum Wire Size AWG | 16AWG |
Key Features
- The terminal block features 3 contacts for secure wiring connections.
- It has a 5.08 mm pitch suitable for standard PCB layouts.
- Constructed with polyamide 66 housing material providing durability and flame retardance.
- Rated for 10A current and 300V voltage for versatile performance.
- Supports wire sizes ranging from 0.13 mm² to 1.31 mm² (26 to 16 AWG).
- It is a single-row terminal block with through hole mount for robust PCB attachment.
- The component is vertically oriented and has a green color for easy identification.
- Designed with professional rising clamp terminals and guided pin alignment for ease of use.
Product Description
The RS PRO CTB0509 is a high-quality PCB Terminal Block designed for reliable and secure electrical connections in industrial and electronic circuit boards. This 3-contact terminal block features a 5.08 mm pitch and through hole mounting style, ensuring compatibility with common PCB layouts and stability during operation.
Constructed from robust polyamide 66 housing, it offers excellent durability along with UL94-V0 flame retardant properties, enhancing safety in demanding environments. The terminal block accommodates wire sizes from 0.13 mm² to 1.31 mm² (26 to 16 AWG), providing flexibility for different wiring requirements.
With a current rating of 10A and voltage rating of 300V, this component is suitable for various industrial, manufacturing, and electronic applications requiring moderate electrical loads. The vertical orientation and green color coding facilitate easy identification and installation on printed circuit boards.
Key design features include the professional rising clamp terminals that ensure secure and efficient wire clamping and a guided pin alignment mechanism that guarantees proper installation and mechanical strength. This single-row 3-contact terminal block offers compact dimensions of 8.3 mm width, 15.14 mm length, and 10.1 mm depth, making it ideal for space-constrained PCB designs.
The RS PRO CTB0509 series is manufactured in China, adhering to high standards of quality and performance. It is widely used in electronics, power and connectors specifically for PCB terminal block applications.
The terminal block features 3 contacts for secure wiring connections. It has a 5.08 mm pitch suitable for standard PCB layouts. Constructed with polyamide 66 housing material providing durability and flame retardance. Rated for 10A current and 300V voltage for versatile performance.
Supports wire sizes ranging from 0.13 mm² to 1.31 mm² (26 to 16 AWG). It is a single-row terminal block with through hole mount for robust PCB attachment. The component is vertically oriented and has a green color for easy identification.
Dimensions are compact with an 8.3 mm width, 15.14 mm length, and 10.1 mm depth. Designed with professional rising clamp terminals and guided pin alignment for ease of use. Manufactured in China according to RS PRO quality standards.
Explore the full range of PCB Terminal Blocks and connectors for your electronics and manufacturing projects here at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this terminal block is 5.08 mm, making it suitable for standard PCB layouts.
It supports wire sizes ranging from 0.13 mm² to 1.31 mm², which corresponds to 26 to 16 AWG.
The dimensions of this terminal block are 15.14 mm in length, 8.3 mm in width, and 10.1 mm in depth.
The housing is constructed from polyamide 66, which provides durability and flame retardance.
This model features a through hole mounting style, ensuring robust attachment to PCBs.
The terminal block is vertically oriented, which aids in installation and space management on PCBs.
It has 3 contacts, allowing for secure wiring connections in electronic circuits.
This terminal block is green in color, which helps with easy identification during installation.
It includes professional rising clamp terminals for secure wire clamping and a guided pin alignment mechanism for proper installation.
Yes, it is suitable for various industrial, manufacturing, and electronic applications requiring moderate electrical loads.
