Molex CLIK-Mate Series Right Angle Surface PCB Socket, 3 Contacts, 1 Row, 2mm Pitch, Solder, 250V, 12A 502494-0370
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 12A |
| Mount Type | Surface |
| Housing Material | Thermoplastic |
| Contact Material | Copper |
| Series | CLIK-Mate |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Wire-to-Board |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Female |
| Connector System | Signal, Wire-to-Board |
Key Features
- Delivered with robust 2.00 mm CLIK-Mate SMT PCB receptacles for versatile applications.
- Features a right angle, surface mount design ideal for compact electronic assemblies.
- Supports up to 12A current and 250V voltage for reliable high-power signal transmission.
- Thermoplastic housing provides high durability and secure strain relief for the solder joint.
- Dual inner positive locking mechanism ensures secure mating and audible click feedback.
- Female contact gender and tin-plated copper contacts for enhanced conductivity and corrosion resistance.
- Suitable for automotive, industrial, smart meters, medical monitors, LED modules, and LCD panels.
- Operating temperature range from -40°C to 105°C, supporting harsh environments.
Product Description
Molex 502494-0370 CLIK-Mate Series Right Angle Surface PCB Socket is a premium wire-to-board connector solution engineered for demanding electronic applications. With a 3-contact configuration in a single row, a 2mm pitch, and surface mount solder termination, this socket is tailored for modern PCB designs requiring space-efficient, reliable connections.
The robust thermoplastic housing delivers exceptional mechanical strength and strain relief, complemented by reinforced metal solder tabs to ensure secure retention on the PCB. Tin-plated copper contacts maximize electrical conductivity and resist corrosion, ensuring long-term performance in electronic assemblies.
Equipped with a dual inner positive locking mechanism, this connector provides audible feedback and mating assurance, preventing accidental disconnections. Mating guides and polarization features facilitate correct installation and help avoid mismating, while the female contact gender meets standard signal wire-to-board requirements.
Designed for wire-to-board applications in signal and power transmission. Right angle orientation supports compact PCB layouts and efficient cable management. 12A current rating and 250V voltage capacity deliver robust electrical performance.
2mm pitch allows for high pin-density layouts without sacrificing reliability. 40°C to 105°C operating range suitable for automotive, industrial, and commercial environments. Pick-and-place features streamline automated PCB assembly processes.
Ideal for use in automotive headlamps, interior mirrors, industrial scanners, smart grid meters, LED light modules, medical patient monitors, surgical equipment, and LCD panels. Compliance with RoHS and industry standards (no additional certifications claimed).
The CLIK-Mate Series is recognized for its secure mating, low insertion force, and compact footprint, serving a wide array of industrial and electronic applications. Explore Molex solutions on EnvMart for enhanced PCB connectivity, reliability, and versatile engineering options in electronic component categories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 12A and a voltage rating of 250V, making it suitable for high-power signal transmission.
The contact pitch for this connector is 2mm, allowing for high pin-density layouts in compact PCB designs.
It features a thermoplastic housing for mechanical strength and tin-plated copper contacts for enhanced conductivity and corrosion resistance.
The operating temperature range for this unit is from -40°C to 105°C, making it suitable for harsh environments.
This model has 3 contacts arranged in a single row, designed for efficient wire-to-board connections.
It uses a solder termination type, which provides a secure connection to the PCB.
This connector features a right angle orientation, which is ideal for compact electronic assemblies and efficient cable management.
This product is compliant with RoHS standards, ensuring it meets environmental regulations.
It is suitable for various applications including automotive, industrial, smart meters, medical monitors, LED modules, and LCD panels.
This model features a female contact gender, which is standard for signal wire-to-board requirements.
Yes, it is equipped with a dual inner positive locking mechanism that provides audible feedback and ensures secure mating.
The country of origin for this PCB socket is Japan.
