Cosel MGW Series DC-DC Converter MGW151215-R, 30V DC/-30V DC, Dual Output, 12V DC Input, 15W, PCB Mount, 85°C Max
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGW DC/DC Converter, 30V dc, -30 V dc/ 500 m |
| Brand | Cosel |
| Efficiency | 88% |
| Length | 25.4mm |
| Model | MGW151215-R |
| Depth | 9.9mm |
| Gross Weight | 20g |
| Width | 9.9mm |
| Mount Type | PCB |
| Series | MGW |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Ripple and Noise | 150mV Pk-Pk |
| Maximum Output Power | 15W |
| Maximum Input Voltage | 12V dc |
| Standards/Approvals | EN 60950-1, TUV, UL 60950-1, CE, cUL, cULus |
| Minimum Input Voltage | 9V |
| Number of Pins | 6 |
| Output Voltage 1 | 30, -30V dc |
| Output Current 1 | 500mA |
| Output Voltage Adjustment Range | 14.602 to 15.505 V |
| Isolation Voltage | 1.5kV dc |
| Output Current 2 | 0.5A |
| High reliability | no built-in aluminium and tantalum electrolytic capacitor |
Key Features
- Maximum output power of 15W ideal for demanding electronic circuits.
- Compact DIP package for PCB mount applications.
- Output current rated at 500mA for stable performance.
- High efficiency of 88% reduces heat generation.
- Isolation voltage of 1.5kV DC ensures robust safety.
- Operates reliably from -40°C to 85°C ambient temperatures.
- Remote On/Off function for flexible system integration.
Product Description
Cosel MGW Series DC-DC Converter MGW151215-R delivers reliable dual output voltages at 30V DC and -30V DC, making it an optimal solution for industrial, electronic, and embedded system applications where precision and stability are critical. Designed for PCB mounting, this converter features a compact DIP package measuring 25.4mm in length and 9.9mm in both depth and width, enabling easy integration into space-constrained layouts.
With an input voltage range from 9V to 12V DC, the MGW151215-R is engineered to supply a maximum output power of 15W and an output current of up to 500mA. Its efficiency rating of 88% ensures minimized power loss, contributing to longevity and consistent operation of sensitive electronics.
Dual output configuration supports both 30V DC and -30V DC, suitable for circuits requiring symmetrical voltage rails. Industry-standard SIP6 footprint and high reliability components. No built-in aluminium or tantalum electrolytic capacitor, increasing operational endurance.
Six-sided shield design enhances EMI immunity for stable performance. I/O isolation voltage of 1,500V DC for safe use in demanding environments. Integrated overvoltage and overcurrent protection provide safety and automatic recovery.
Built-in remote On/Off function allows system-level power control.
The MGW151215-R offers a ripple and noise specification of 150mV Pk-Pk, an adjustable output voltage range between 14.602V and 15.505V, and complies with EN 60950-1, TUV, UL 60950-1, CE, and cUL certifications. Operating reliably in temperatures from -40°C to 85°C, it is suitable for industrial, laboratory, telecom, and high-reliability commercial systems.
Its lightweight design (20g) and DIP package facilitate straightforward PCB assembly, while the robust isolation and wide input range make it a cornerstone for multi-rail DC conversion needs in advanced electronics and automation projects.
Explore more DC-DC Converters from Cosel in the EnvMart electronics catalogue for solutions tailored to industrial, laboratory, and embedded system requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 15W, making it suitable for demanding electronic circuits.
It provides dual output voltages of 30V DC and -30V DC, supporting circuits that require symmetrical voltage rails.
This unit operates with an input voltage range from 9V to 12V DC.
The efficiency rating of the MGW151215-R is 88%, which helps reduce heat generation during operation.
The dimensions of this model are 25.4mm in length, 9.9mm in width, and 9.9mm in depth.
It has an isolation voltage of 1.5kV DC, ensuring robust safety in demanding environments.
The ripple and noise specification is 150mV Pk-Pk, contributing to stable performance in electronic circuits.
The MGW151215-R operates reliably in ambient temperatures ranging from -40°C to 85°C.
Yes, it features integrated overvoltage and overcurrent protection for enhanced safety and automatic recovery.
This converter is designed for PCB mounting, utilizing a compact DIP package.
It complies with several standards, including EN 60950-1, TUV, UL 60950-1, CE, and cUL certifications.
The weight of this model is 20g, making it lightweight for easy PCB assembly.
