Phoenix Contact Safety Relay 24V DC, 3 Safety Contacts, DIN Rail Mount, PSR-SPP Series 2981813
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Phoenix Contact |
| Height | 112mm |
| Length | 50mm |
| Model | 2981813 |
| IP Rating | IP20 |
| Mounting Type | DIN Rail |
| Width | 22.5mm |
| Mount Type | DIN Rail |
| Housing Material | Polyamide |
| Series | PSR-SPP |
| Maximum Operating Temperature | 45°C |
| Time Delay | 0.1 to 30 s |
| Minimum Operating Temperature | -20°C |
| Safety Category | PLe, EN ISO 13849, CAT 4 |
| Terminal type | Push-in |
| Standards/Approvals | IEC 61508, EN ISO 13849-1, IEC 62061 |
| Reset Method | Automatic or Manual |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 250V dc |
| Switching AC Voltage | 250V ac |
| Contact Current | 6A |
| Safety Contacts | 3 |
Key Features
- Certified for IEC 61508, EN ISO 13849-1, and IEC 62061 standards.
- Supports automatic or manual reset for operational flexibility.
- DIN rail mountable for easy panel integration.
- Adjustable time delay from 0.1 to 30 seconds.
- Three independent safety output contacts for redundancy.
- Compatible with switching voltages up to 250V AC/DC.
- Handles contact current up to 6A for industrial use.
- Supplied in IP20-rated polyamide housing.
Product Description
Phoenix Contact 2981813 Safety Relay is engineered for high-integrity safety circuit needs in industrial and automation environments. This 24V DC safety relay is equipped with 3 safety contacts and ensures reliable emergency stop and safety door monitoring, making it ideal for safeguarding personnel and equipment in manufacturing, processing, and automation plants.
With certifications to major safety standards including IEC 61508, EN ISO 13849-1 (PLe, CAT 4), and IEC 62061, the relay is suitable for integration into SIL and PL-rated safety systems. Its automatic or manual reset capability allows custom configuration according to operational safety requirements.
Certified for IEC 61508, EN ISO 13849-1, and IEC 62061 compliance, supporting use in advanced safety-critical applications. Three safety contacts provide robust redundancy, essential for multi-channel emergency stop circuits.
Time delay adjustable from 0.1 to 30 seconds supports timed safety relay interventions for machinery stop functions. Contact current of up to 6A and switching voltage up to 250V AC/DC ensure compatibility with a wide range of devices.
DIN rail mount design speeds up panel installation and facilitates compact, modular safety solutions. Reset method selection (automatic/manual) enhances flexibility for both operator-initiated and automatic restart configurations.
Push-in terminal connections help simplify and secure wiring during installation or maintenance routines. Polyamide housing rated to IP20 for indoor industrial deployments, with minimum installation location protection of IP54.
Featuring compact dimensions of 22.5mm width, 112mm height, and 50mm length, this relay provides significant space-saving benefits for panel builders and OEMs. Typical applications include industrial automation panels, machine tools, conveyor systems, safety interlocks for access doors, and process machinery requiring stringent safety monitoring and quick-response safety relays.
Designed for reliability and longevity, the Phoenix Contact PSR-SPP 2981813 supports demanding use cases in industrial automation, process industries, and manufacturing environments.
Discover more options in Safety Relays or browse Phoenix Contact’s full range for industrial safety solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this safety relay is 24V DC.
This model has dimensions of 22.5mm in width, 112mm in height, and 50mm in length.
It can handle a maximum contact current of 6A.
The adjustable time delay for this safety relay ranges from 0.1 to 30 seconds.
The housing of this safety relay has an IP rating of IP20.
It is certified for IEC 61508, EN ISO 13849-1, and IEC 62061 standards.
This relay is equipped with three independent safety contacts.
This safety relay is designed for DIN rail mounting.
The minimum operating temperature for this relay is -20°C.
It supports both automatic and manual reset methods for operational flexibility.
It can handle switching voltages up to 250V AC and 250V DC.
The housing of this safety relay is made from polyamide.
