KEMET Polypropylene Film Capacitor, 120 nF, 630V DC, 250V AC, 5% Tolerance, Through Hole R75PI312050H3J
Specifications
| Country of Origin | China |
|---|---|
| Brand | KEMET |
| Height | 13.5mm |
| Length | 18mm |
| Model | R75PI312050H3J |
| Packaging | Tape & Reel |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | R75 |
| Maximum Operating Temperature | 105°C |
| Tolerance | 5 % |
| Capacitance | 120nF |
| Minimum Operating Temperature | -55°C |
| Dissipation Factor | 0.05% |
| Lead Length | 25mm |
| Standards/Approvals | RoHS, IEC 60286-2 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 250V ac |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Equivalent Series Resistance ESR | 13.3mΩ |
Key Features
- Provides 120 nF capacitance for efficient circuit performance.
- Rated for 630V DC and 250V AC, ideal for demanding applications.
- 5% tolerance ensures reliability in voltage regulation.
- Through hole mounting is suitable for secure PCB installation.
- Automotive standard AEC-Q200 compliant.
- Encapsulated in solvent resistant plastic and thermosetting resin material.
- Minimum operating temperature of -55°C and maximum operating temperature of 105°C, supporting harsh environments.
- Lead free, RoHS compliant, and self-healing construction.
Product Description
KEMET R75PI312050H3J Polypropylene Film Capacitor offers high reliability and precise capacitance for demanding electronic applications. This 120 nF, 630V DC, 250V AC capacitor features a 5% tolerance and a robust through hole mounting, making it ideal for medium to high current circuits and automotive environments.
The R75 series is manufactured with metallized polypropylene film and radial leads of tinned wire, encapsulated in a self-extinguishing, solvent resistant plastic case filled with thermosetting resin for enhanced durability and safety. With a lead pitch of 15 mm, lead length of 25 mm, and 0.8 mm lead diameter, it is optimized for PCB integration.
This capacitor is compliant to automotive standard AEC-Q200 and RoHS, with approvals including IEC 60286-2. Its dissipation factor of 0.05% and ESR of 13.3 mΩ ensure efficient energy performance and reduced losses. The part operates reliably within a temperature range of -55°C to 105°C, suitable for harsh and industrial environments.
Provides 120 nF capacitance for efficient signal filtering and circuit stabilization. Rated for 630V DC and 250V AC, supporting both high voltage DC and AC applications. 5% tolerance for consistent circuit performance even in sensitive configurations.
Through hole mounting and tape & reel packaging enable easy automated assembly in PCB manufacturing. Automotive standard AEC-Q200 compliance assures reliability for automotive electronics. Encapsulated construction for thermal and chemical stability in industrial settings.
Wide operating temperature range makes it a fit for laboratory, manufacturing, and commercial installations. Self-healing and lead-free termination contribute to long life and environmental safety. Two pin configuration for straightforward circuit integration.
Plastic case protects against environmental factors and mechanical stress.
Typical applications include resonant circuits, silicon controlled rectifier circuits, power supply filtering, and industrial electronics. The compact 18 x 7.5 x 13.5 mm form factor suits dense PCB layouts.
Choose KEMET capacitors from EnvMart for reliable film capacitor solutions across electronics manufacturing, automotive, laboratory, and power electronics industries.
Explore more products in our Film Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a capacitance of 120 nF, suitable for efficient circuit performance.
It is rated for 630V DC and 250V AC, making it appropriate for both high voltage DC and AC applications.
The tolerance of this capacitor is 5%, ensuring reliability in voltage regulation.
This capacitor operates reliably within a temperature range of -55°C to 105°C, suitable for harsh environments.
It features a through hole mounting type, which is suitable for secure PCB installation.
It is encapsulated in a solvent resistant plastic case filled with thermosetting resin, enhancing durability and safety.
The dimensions are 18 mm in length, 7.5 mm in width, and 13.5 mm in height.
The equivalent series resistance (ESR) is 13.3 mΩ, which contributes to efficient energy performance.
It is compliant with automotive standard AEC-Q200 and RoHS, with approvals including IEC 60286-2.
The dissipation factor is 0.05%, which helps in reducing energy losses.
It has a two pin configuration, optimized for straightforward circuit integration.
This model is packaged in tape & reel, facilitating easy automated assembly in PCB manufacturing.
