Wurth Elektronik WR-MPC3 Vertical Through Hole PCB Header, 12 Contacts, 3mm Pitch, Shrouded, 1 Row, 250V, 5A, MPC3
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Vertical |
| Current | 5A |
| Model | MPC3 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | WR-MPC3 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Vertical through hole PCB header designed for robust wire-to-board connectivity.
- 12 contact positions with a 3mm pitch for space-efficient PCB layouts.
- Shrouded single row style ensures reliable insertion and protection against accidental contact misalignment.
- Rated for up to 250V and 5A, suitable for power and signal circuits.
- Copper alloy contacts with tin plating provide excellent conductivity and corrosion resistance.
- Housing made from liquid crystal polymer (LCP) for durability and high-temperature tolerance.
- Solder termination for secure and stable mounting to the PCB.
- Operating temperature range from -40°C to 105°C supports industrial applications.
Product Description
Wurth Elektronik 66201211122 WR-MPC3 Vertical Through Hole PCB Header is a reliable wire-to-board solution engineered for demanding electronics applications. Featuring 12 contact positions separated by a precise 3mm pitch, this shrouded single-row header delivers stable connectivity and ensures accurate insertion alignment.
Vertical PCB Header provides direct and robust wire-to-board interfacing, supporting industrial, commercial, and laboratory electronics. The shrouded design enhances protection by preventing accidental contact disengagement or misalignment, maintaining system integrity under vibration or mechanical stress.
Rated for 250V and 5A, the header is suitable for both signal and moderate power transmission, making it versatile for a wide range of PCB designs. Copper alloy contacts plated in tin guarantee consistent electrical performance and improved corrosion resistance for enhanced longevity.
Liquid crystal polymer (LCP) housing offers high strength and stability, enabling reliable operation at temperatures from -40°C to 105°C. Solder termination type ensures secure mechanical mounting for lasting durability.
Male contacts suit standard wire-to-board housings and connectors, simplifying integration into existing circuit designs.
This WR-MPC3 Series header meets RoHS compliance and is backed by Wurth Elektronik’s reputation for quality and innovation in electronic components. Applications include PCB assembly for power supplies, signal lines, measuring instruments, industrial control boards, and consumer electronics.
Designed for versatility and performance, this connector supports various environments such as manufacturing, process control, test and measurement, and laboratory setups. Explore more PCB connectors, headers, and accessories in the Electronics Components category at EnvMart, or browse Wurth Elektronik’s portfolio for additional solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The WR-MPC3 PCB header is rated for a voltage of 250V.
This model can handle a current of up to 5A.
The contact positions of this PCB header are spaced at a pitch of 3mm.
The housing of the WR-MPC3 is made from liquid crystal polymer (LCP).
This PCB header features 12 contact positions.
The WR-MPC3 uses solder termination for secure mounting to the PCB.
The operating temperature range for this unit is from -40°C to 105°C.
This model supports a wire-to-board connector system.
Yes, the WR-MPC3 PCB header meets RoHS compliance standards.
The orientation of this PCB header is vertical.
The contacts of the WR-MPC3 are male and made from copper alloy with tin plating.
The WR-MPC3 is manufactured in Taiwan.
