RS PRO PAS6 Series Momentary Push Button Switch, Panel Mount, 13.6 mm Cutout, SPST, White LED, IP67, 36V DC 250V AC PAS6

RS PRO PAS6 Series Momentary Push Button Switch combines robust mechanical performance with versatile electrical ratings for demanding panel-mounted applications. Designed to fit a 13.6 mm cutout and equipped with a SPST configuration, it’s ideal for machine control and process activation tasks.

The actuator is flat and features a white LED for clear visual feedback, manufactured from high-quality polyamide 6/6 ensuring durability and excellent tactile response. The IP67 rating allows this switch to withstand dust and water exposure, making it suitable for indoor and outdoor settings.

Reliable electrical performance is achieved via solder terminals, supporting voltage ratings up to 36V DC and 250V AC. Its contact current is rated at 125mA, and the switch is designed for momentary operation (Off-(On)), providing precise manual activation.

This push button switch is panel-mounted and fits a 13.6 mm cutout. SPST contact configuration for single circuit control, momentary type (Off-(On)). Actuator is flat, white, and constructed of polyamide 6/6. White LED provides illuminated indication in operational mode.

IP67 rating ensures resistance to water and dust ingress. Wide operating temperature from -35°C to 85°C for varied industrial environments. Supports 36V DC and 250V AC with a maximum contact current of 125mA. Gold over silver-plated contacts for reliable performance.

With a mechanical life exceeding 1,000,000 cycles and contact bounce limited to 10 ms, this switch is engineered for longevity and precision. Typical applications include test equipment, telecommunications, networking, handheld appliances, and industrial control panels.

Panel mounting is facilitated by standard M12 x 0.75 threading and panel thickness support from 1.5 mm to 4 mm. Operating force ranges between 2N and 5N, ensuring a responsive push action.

Choose RS PRO PAS6 Push Button Switches when you need reliable, compact switching with visual feedback in electrical and automation panels. Browse more RS PRO switches and components for industrial, laboratory, and automation applications with EnvMart.
