RS PRO Illuminated Push Button Switch, Momentary, Panel Mount, 13.6 mm Cutout, SPST, Green LED, IP67, 36 V DC 50 V AC PAS6

RS PRO PAS6 Illuminated Push Button Switch is designed for demanding environments and industrial controls. Featuring a flat black actuator with bright green LED illumination, it supports momentary operation and is ideal for signaling and control panels.

This push button switch is easily panel mounted with a 13.6 mm cutout and operates using single-pole, single-throw (SPST) configuration. High reliability is ensured with gold over silver contacts and an epoxy sealed polyamide body, maintaining integrity in wet or dusty environments due to its IP67 protection rating.

Provides reliable switching performance with single-pole, single-throw configuration. Fitted with a flat black actuator and bright green LED for clear visible indication. Designed for quick panel mounting with a 13.6 mm cutout and solder terminal connection.

Sealed to IP67, suitable for harsh environments and industrial applications. Operates within a wide voltage range, supporting both 36 V DC and 50 V AC. Gold over silver contacts and polyamide body for superior durability.

Tested for up to 1,000,000 mechanical cycles for long operational life.

Applications include test equipment, telecommunications, networking devices, and handheld appliances where robust and illuminated signalling is required. The PAS6 series is widely used in industrial, laboratory, automation, and electrical panel applications.

Mounting is user-friendly due to the threaded bushing or snap-in option. Compatible with solder terminal wiring and offers versatility with multiple actuator colors and LED options. Minimum operating temperature is -35°C and maximum is 85°C, making it suitable for a wide range of operating environments.

Explore the complete range of RS PRO Push Button Switches for quality and reliability in electrical and automation systems.
