TDK-Lambda DC/DC Converter 15V DC Output, 1A, 18 - 76V DC Input, 15W, Through Hole CCG15
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters TDK-Lambda CCG15 DC/DC Converter, 15V dc/ 1 A, 76V |
| Brand | TDK-Lambda |
| Efficiency | 88% |
| Length | 25.4mm |
| Model | CCG15 |
| Depth | 9.9mm |
| Gross Weight | 20g |
| Width | 9.9mm |
| Mount Type | Through Hole |
| Series | CCG15 |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 3191064h |
| Number of outputs | 1 |
| Ripple and Noise | 95mV Pk-Pk |
| Maximum Output Power | 15W |
| Maximum Input Voltage | 76V dc |
| Standards/Approvals | UL/CSA 60950-1, CE, EN 60950-1 |
| Minimum Input Voltage | 18V |
| Number of Pins | 6 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 1A |
| Output Voltage Adjustment Range | 13.5 to 16.5 V |
| Isolation Voltage | 500V dc |
Key Features
- Provides reliable and stable 15V DC output with 1A current.
- Accepts a broad 18 - 76V DC input voltage range for versatility.
- Compact 15W design ensures efficient power conversion.
- Integrated through-hole mount is ideal for PCB assembly.
- MTBF rated at over 3.1 million hours for dependable operation.
- Six-sided metallic shielding minimizes noise and electromagnetic interference.
- Output voltage is adjustable from 13.5 to 16.5V for flexible application requirements.
- Remote on/off and multiple protection features enhance system integration.
Product Description
TDK-Lambda CCG15-48-15S is an advanced isolated DC-DC Converter delivering a regulated 15V DC output at up to 1A, optimized for use in industrial, test, and communications equipment. Its input range of 18 - 76V DC and output capacity of 15W make it highly suitable for systems requiring robust, efficient power conversion and noise reduction.
The converter is packaged in a DIP format with through-hole mounting, supporting easy PCB assembly for integration into industrial controllers, factory automation, and general-purpose electronics. The device’s compact 1"×1" footprint and metallic case provide six-sided shielding, substantially reducing radiated and conducted emissions. System designers benefit from a high efficiency of 88%, resulting in less heat and simpler thermal management.
Key performance features include remote on/off capability, output voltage adjustment from 13.5 to 16.5V, and ripple/noise control to 95mV peak-to-peak. The converter’s isolation voltage is rated at 500V DC, and protection features span input/output safety, vibration resistance, and shock compliance.
Reliability is a core aspect, with an MTBF of over 3 million hours, and the product is certified to UL/CSA 60950-1, CE, and EN 60950-1 standards. Operating temperatures range from −40°C to +85°C, enabling use in demanding environments. Its six-pin DIP package further streamlines electronic system design and maintenance.
Typical applications include test and measurement instruments, broadcast and telecom equipment, factory automation, process control systems, and commercial electronics requiring regulated DC conversion, noise minimization, and system reliability.
For more DC-DC power solutions from TDK-Lambda and to explore the complete EnvMart industrial electronics catalog, visit the category pages for converters and power supplies.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The converter accepts a broad input voltage range of 18 to 76V DC.
This model provides a maximum output power of 15W.
It has an efficiency rating of 88%, which contributes to effective power conversion and thermal management.
The output voltage can be adjusted from 13.5V to 16.5V, allowing for flexibility in application requirements.
The dimensions of this model are 25.4mm in length, 9.9mm in width, and 9.9mm in depth.
The isolation voltage is rated at 500V DC, ensuring safe operation in various applications.
It operates effectively within a temperature range of -40°C to +85°C.
The ripple and noise level is controlled to 95mV peak-to-peak.
This unit features a through-hole mount, making it suitable for PCB assembly.
It is certified to UL/CSA 60950-1, CE, and EN 60950-1 standards.
The MTBF is rated at over 3.1 million hours, indicating a high level of reliability.
This model has one output, providing a regulated 15V DC at up to 1A.
