Hirose FunctionMAX Series Right Angle Through Hole PCB Socket, 2 Contact, 2 Row, 7.62mm Pitch, 17A, Solder, Polyamide FX30B

The Hirose FX30B-2S-7.62DS PCB Socket is a high-reliability connector engineered for demanding board-to-board power and signal applications. Featuring two contacts arranged in two rows, this socket is designed for board-to-board mounting with parallel, vertical, or coplanar configurations. Its 7.62mm pitch and right angle orientation make it suitable for compact and dense PCB layouts.

The socket supports a high current rating of 17A per contact and a voltage rating of up to 600V, making it ideal for industrial power applications. The through hole mounting delivers strong mechanical stability, while solder termination ensures a robust and lasting electrical connection. The polyamide resin housing provides outstanding insulation and mechanical durability, protecting the contacts and maintaining performance in harsh environments.

This Hirose FunctionMAX FX30B connector features gold-plated copper contacts that offer superior conductivity, multi-point contact structure, and resistance to corrosion. Its floating structure design absorbs mounting misalignment, reducing stress, preventing solder cracking, and eliminating the need for corrective rework. Large mating guides and secure metal fittings further enhance alignment and mechanical connection, maintaining integrity under vibration or movement.

The connector has an effective mating length of 2mm, supporting repeated connections and high contact reliability. Its wide operating temperature range from -55°C to 105°C makes it suitable for a diverse set of industrial, laboratory, communications, and medical applications. Typical use cases include broadcast equipment, base station transceivers, industrial control units, measurement instruments, and projectors.

Engineered for maximum reliability and performance, the Hirose FX30B-2S-7.62DS PCB socket is a premium choice for professionals requiring precise, robust, and misalignment-absorbing connectors for advanced electronic systems.

Board-to-board socket with two contacts for secure power and signal transmission. Right angle orientation and through hole design ensures strong mechanical stability. 17A high current capacity and 600V operation for industrial-grade projects.

Solder termination and polyamide resin housing for durability and electrical insulation. Gold-plated copper contacts and multi-point contact structure for reliability.

This product belongs to the PCB Socket category within Electronics & Electricals. For more Hirose connectors and advanced board-to-board solutions, explore the FunctionMAX series and related PCB Socket products on EnvMart.
