Microchip MCP609-I/SL Operational Amplifier 4 Channels 155 kHz Gain Bandwidth 14-Pin SOIC 6V
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.25mm |
| Length | 8.65mm |
| Model | MCP609-I/SL |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | MCP609 |
| Output Current | 17mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 2.5V |
| GBP - Gain Bandwidth Product | 155kHz |
| Input Bias Current | 80 pA |
| Slew Rate | 0.08V/μs |
| Input Offset Current | 1 pA |
Key Features
- Designed with surface mount SOIC package for easy PCB integration.
- Provides four channels for multi-signal amplification requirements.
- Offers a gain bandwidth product of 155 kHz for reliable signal performance.
- Operates from a supply voltage range of 2.5V to 6V to suit diverse electronic designs.
- Features a low input bias current of 80 pA and input offset voltage of ±250 μV.
- Supports a slew rate of 0.08 V/μs for smooth transitions.
- Rated for automotive standard AEC-Q100 and RoHS compliant.
Product Description
The Microchip MCP609-I/SL is a high-performance operational amplifier suited for precision analog signal processing and amplification tasks in both industrial and automotive electronics. With four independent channels, it is engineered to deliver consistent, low-noise amplification across multiple inputs, making it ideal for designs requiring integrated multi-channel operations.
Designed in a 14-pin SOIC surface mount package, the MCP609-I/SL amplifier is easy to implement in modern printed circuit boards, optimizing space and improving production efficiency. The gain bandwidth product of 155 kHz ensures reliable frequency response and fidelity, suitable for active filter, signal conditioning, and sensor interface circuits.
This device supports operation at supply voltages from 2.5V up to 6V, accommodating varying power requirements in embedded systems, measurement instruments, and control applications. Low input bias current (80 pA) and input offset voltage (±250 μV) contribute to precise and stable performance, even in high-accuracy settings.
With a slew rate of 0.08 V/μs, the MCP609-I/SL achieves smooth output transitions while its output current capability of up to 17 mA allows it to drive moderate loads. Automotive standard certification (AEC-Q100) and RoHS compliance make it appropriate for robust applications, including automotive signal chains, industrial controllers, and reliable instrumentation circuits.
Package dimensions are compact, with length 8.65 mm, width 3.9 mm, and height 1.25 mm, fitting space-constrained designs while offering durability and reliability. Typical application areas include industrial measurement, control, automotive electronics, and advanced signal processing modules in laboratory and commercial equipment.
Operational amplifier for industrial, automotive, and laboratory signal processing. Multi-channel support facilitates integrated circuits and complex analog systems design. Suitable for signal conditioning, active filtering, and measurement applications.
Explore the full range of Operational Amplifiers and semiconductor solutions from Microchip in the Op Amps category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 155 kHz, ensuring reliable frequency response for various applications.
It operates from a supply voltage range of 2.5V to 6V, accommodating different power requirements in electronic designs.
This operational amplifier features four independent channels, allowing for multi-signal amplification.
The input bias current is 80 pA, contributing to its precision in high-accuracy applications.
The package dimensions are 8.65 mm in length, 3.9 mm in width, and 1.25 mm in height, making it suitable for space-constrained designs.
It can provide an output current of up to 17 mA, allowing it to drive moderate loads effectively.
The slew rate is 0.08 V/μs, which enables smooth output transitions in signal processing applications.
The operational amplifier can function within a temperature range of -40°C to 85°C, suitable for various environments.
Yes, it is RoHS compliant, ensuring it meets environmental standards for hazardous substances.
This model features a surface mount design, facilitating easy integration into printed circuit boards.
It is rated for the automotive standard AEC-Q100, making it suitable for automotive applications.
The input offset voltage is ±250 μV, which helps maintain stability and accuracy in signal processing tasks.
