TE Connectivity Disk Drive Surface Mount Connector, Solder Termination, Male, 12A 250V AC, Phosphor Bronze, Nylon 770149-1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V ac |
| Brand | TE Connectivity |
| Current | 12A |
| Model | 770149-1 |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | -55°C |
| Minimum Operating Temperature | -105°C |
| Standards/Approvals | RoHS, CSA, UL |
| Contact Plating | Tin |
| Contact Gender | Male |
| Connector Gender | Male |
Key Features
- Disk drive connector with right angle surface mount design for efficient PCB layout.
- Rated for 12A maximum current and 250V AC for demanding electrical applications.
- Features male gender and solder termination for secure, reliable connections.
- Housing constructed from durable nylon and contact material is phosphor bronze with tin plating for long service life.
- Complies with RoHS, CSA, and UL standards for high safety and reliability.
- Suitable for general I/O power connections and interfaces directly with disk drives.
Product Description
The TE Connectivity 770149-1 Disk Drive Connector is a high-performance surface mount plug designed for secure and reliable power connections in various electronic and industrial assemblies. Engineered with a compact right angle layout, it enables efficient interfacing with disk drives and other devices on printed circuit boards, where compact structure and high current-carrying capacity are crucial.
This connector supports up to 12A of continuous current at 250V AC, making it ideal for devices requiring robust power supply and distribution. The male connector configuration with solder-type terminations ensures steadfast connection integrity while allowing for convenient soldering during assembly and manufacturing.
Constructed with a nylon housing and phosphor bronze contacts plated with tin, this connector offers excellent mechanical durability, corrosion resistance, and reliable electrical conductivity under demanding conditions. It supports surface mounting to a PCB with a recommended board thickness of 1.6 mm, increasing its versatility for numerous design requirements.
The product's compliance with RoHS, CSA, and UL certifications attests to its safety and suitability for use in regulated environments, including commercial, industrial, laboratory, data storage, and general electronic equipment designs.
Key use cases include integration into disk drives, industrial and laboratory equipment, power supplies, and other high-reliability electronics requiring robust board-to-device power transmission. Its operating range supports a wide temperature envelope, ensuring reliable performance even in challenging thermal environments.
An optimal pick for OEMs, PCBA manufacturers, and device repair specialists seeking a blend of high-current operation, compact form factor, and international compliance in board-level connectors.
Browse more TE Connectivity connectors and related electronic components in the Power Connector category on EnvMart.
